神钢零件查询(MD320BLC) - EXCAVATOR BTW YC0301 - YC0747 (1/80-12/06) (05-005) - RADIATOR ASSY Kobelco
广数供应链运营团队, 15 02月, 2025，浏览：
912 次
| Pos. | Part No | Qty | Parts name | Comments |
|---|
| . . | 2452U405F1 | [1] | RADIATOR RADIATOR ASSY | RADIATOR RADIATOR ASSY |
| 1. | 2452U405S1 | [1] | RADIATOR | KOBRADIATOR CORE |
| 2. | 2452U405S2 | [1] | OIL COOLER | KOB |
| 3. | 2452U405S3 | [1] | SHROUD | KOB |
| 4. | 2452U405S4 | [1] | FRAME | FRAME |
| 5. | 2452U221S111 | [1] | CAP | KOBPRESSURE Superseded by part number: 2414Z262 |
| 6. | 2452U405S6 | [1] | PIPE | KOB |
| 7. | 2452U221S113 | [2] | CLIP | KOB Superseded by part number: 2452U267S8 |
| 8. | 2452U255S7 | [1] | COCK | KOB Superseded by part number: 2452U221S18 |
| 9. | 2452U405S9 | [1] | PIPE | KOB |
| 10. | 2452U377S25 | [1] | CLIP | KOBCLIP |
| 11. | 2452U405S11 | [2] | PACKING | KOB |
| 12. | 2452U405S12 | [4] | PACKING | KOB |
| 13. | 2452U405S13 | [2] | PACKING | KOB |
| 11. | 2452U405S14 | [24] | SCREW | KOB |
| 17. | 2452U405S17 | [1] | GUARD, FAN | GUARD, FAN |
| 18. | 2452U405S18 | [4] | BOLT ASSY | |
| 19. | 2452U405S19 | [1] | PROTECTOR | KOB |
| 20. | 2452U221S4 | [4] | SCREW | KOB Superseded by part number: 2452U202S5 |
| 21. | 2452U405S21 | [2] | SEAL | KOB |
| 22. | 2452U405S22 | [2] | SEAL | KOB |
| 23. | 2452U405S23 | [1] | PROTECTOR | KOB |
| 24. | 2452U405S24 | [1] | PLATE | |
| 25. | 2452U405S25 | [4] | PLATE | |
| 26. | 2452U405S26 | [8] | BOLT | KOBCAPSCREW Superseded by part number: ZM22C08020 |
