凯斯零件查询(FLX810) - FLEX-AIR APPLICATOR (10/03-8/09) (02-017) - VALVE BOX GROUP, DOUBLE & TRIPLE BIN Case Agriculture
广数供应链运营团队, 15 02月, 2025，浏览：
1007 次
| Pos. |
Part No |
Qty |
Parts name |
Comments |
| 1. |
BN307047
|
[4] |
PIN
|
BN
3/8 With Shoulder
|
| 2. |
87268848
|
[1] |
BOX
|
TYR
Valve - 438A Superseded by part number: 84130864
|
| 3. |
BN306268
|
[1] |
COVER
|
BN
Access, Valve Box Superseded by part number: 84558910
|
| 4. |
BN310283
|
[2] |
PIN
|
BN
3/8 With .75 Shoulder
|
| 5. |
BN50138
|
[2] |
WASHER,1/4", SS
|
BN
|
| 6. |
BN50142
|
[6] |
WASHER,5/16", Stainless Steel
|
BN
|
| 7. |
BN50146
|
[10] |
WASHER,3/8", Stainless
|
BN
|
| 8. |
BN50212
|
[2] |
BOLT,1/4"-20 x 3/4", Stainless Steel
|
BN
|
| 9. |
BN50258
|
[4] |
BOLT,3/8"-16 X 1.25", Stainless
|
BN
|
| 10. |
BN50476
|
[6] |
BOLT,5/16"-18 x 0.75", Stainless
|
BN
|
| 11. |
BN50759
|
[10] |
LOCK NUT,3/8"-16, Nylon, Stainless
|
BN
|
| 12. |
BN52033
|
[4] |
BOLT,1/4"-20 X 5/8", Stainless Steel
|
BN
|
| 13. |
BN55359
|
[6] |
LOCK NUT,1/4"-20, SS
|
BN
|
| 14. |
BN55361
|
[6] |
NUT,5/16"-18, Nylon, Stainless
|
BN
|
| 15. |
BN65808
|
[2] |
LATCH
|
BN
Adjustable Draw
|
| 17. |
BN67852
|
[1] |
COVER
|
BN
Side, RH
|
| 18. |
BN67855
|
[1] |
COVER
|
TYR
Side, LH
|
| 19. |
BN67857
|
[2] |
ANGLE
|
BN
Mount, Side Cover
|
| 20. |
BN71007
|
[6] |
CLIP,3/16" Hairpin
|
BN
Hairpin, 3/16" #8
|
| 21. |
87265990
|
[1] |
PLUG
|
BN
Button, Flush Type
|
| 22. |
87271165
|
[1] |
CABLE,713mm L
|
BN
Breakaway, 28"
|
| 23. |
BN311038
|
[1] |
NUT
|
BN
5/16-18 X 2, HH, SS
|
| 24. |
BN23452
|
[12] |
WASHER,13/32" x 1.25 " OD x 12 GA, SS
|
BN
|
| 25. |
87268865
|
[2] |
RETAINER COLLAR
|
BN
Hinge, Door
|
| 26. |
BN50232
|
[2] |
BOLT,5/16"-18 x 1.00", Stainless Steel
|
BN
|
