凯斯零件查询(FLX810) - FLEX-AIR APPLICATOR (10/03-8/09) (02-020) - VALVE BOX GROUP, TRIPLE BIN Case Agriculture
广数供应链运营团队, 15 02月, 2025，浏览：
752 次
| Pos. |
Part No |
Qty |
Parts name |
Comments |
| 1. |
NS
|
[1] |
NOT SERVICED
|
BAS
Box, Group, Valve 438A
|
| 2. |
344012A1
|
[1] |
HYDRAULIC VALVE
|
BN
8 section manifold
|
| 4. |
BN50144
|
[6] |
LOCK WASHER
|
BN
5/16, LW, SS
|
| 5. |
16043224
|
[4] |
BOLT,Hex, M8 x 16mm, Cl 8.8
|
NH
|
| 6. |
BN50476
|
[6] |
BOLT,5/16"-18 x 0.75", Stainless
|
BN
|
| 9. |
87267730
|
[1] |
HYDRAULIC VALVE
|
BN
Manifold, Triple With Fittings
|
| 9. |
87267730R
|
[1] |
REMAN-HYD VALVE
|
RAC
Reman Manifold, Triple With Fittings
|
| 9. |
87267730C
|
[1] |
CORE-VALVE HYD
|
RAC
Core Return Number
|
