凯斯零件查询(FLX810) - FLEX-AIR APPLICATOR (10/03-8/09) (02-022) - DOOR GROUP, VALVE, OPTIONAL, VIPER Case Agriculture
广数供应链运营团队, 15 02月, 2025，浏览：
865 次
| Pos. |
Part No |
Qty |
Parts name |
Comments |
| 1. |
87268843
|
[1] |
DOOR
|
BN
Valve, Electric Superseded by part number: BN50697, BN50138, 87266738, 87266728, 113-2299, 87266734, 87268842, BN55359, 87270007, 87266729
|
| 2. |
87268865
|
[2] |
RETAINER COLLAR
|
BN
Hinge, Door
|
| 3. |
87271165
|
[1] |
CABLE,713mm L
|
BN
Breakaway, 28"
|
| 4. |
BN50232
|
[2] |
BOLT,5/16"-18 x 1.00", Stainless Steel
|
BN
|
| 5. |
BN311038
|
[1] |
NUT
|
BN
5/16-18 X 2, HH, SS
|
| 6. |
BN55361
|
[5] |
NUT,5/16"-18, Nylon, Stainless
|
BN
|
| 7. |
BN23452
|
[3] |
WASHER,13/32" x 1.25 " OD x 12 GA, SS
|
BN
|
| 8. |
87265700
|
[1] |
BUSHING
|
BN
Door Retainer
|
