| . . | 24100J10339F2 | [1] | BOOM ASSY, 6.5M | |
| 1. | 2411J3412F1 | [1] | BOOM | BOOM |
| 1-1. | 2411J3412 | [1] | BOOM | |
| 1-31. | 2405T1108 | [2] | BUSHING | KOB |
| 1-32. | 2418T9816 | [1] | SPACER | KOB |
| 2. | 2438U776F2 | [2] | CYLINDER | KOBASSY |
| 3. | 2438U1323F2 | [1] | CYLINDER | KOB |
| 4. | 2418P11325D2 | [1] | TUBE | KOB |
| 5. | 2418P11325D1 | [1] | TUBE | KOB |
| 6. | 2418P19977D2 | [1] | TUBE | KOB |
| 7. | 2418P19977D1 | [1] | TUBE | KOB |
| 8. | 2418T18870 | [1] | TUBE | KOB |
| 9. | 2418P20195 | [1] | TUBE | KOB |
| 10. | 2418N2784 | [2] | TUBE | KOB |
| 11. | 2418P20194 | [2] | TUBE | KOB |
| 12. | 2418P10051D1 | [1] | TUBE | KOB |
| 13. | 2418P10051D2 | [1] | TUBE | KOB |
| 14. | ZX28P16120 | [2] | FLEXIBLE HOSE | KOB |
| I5. | 2420R349D170 | [2] | FLEXIBLE HOSE | KOB1700mm Long (66-59/64 in) Superseded by part number: HX21E04170DX |
| 16. | 2420R349D320 | [2] | HOSE ASSY. | KOB3200mm Long (126 in) |
| 17. | 2420R349D380 | [1] | FLEXIBLE HOSE | KOB3800mm Long (149-39/64 in) Superseded by part number: HX21E04380DX |
| 18. | ZF23B35000 | [2] | HYD CONNECTOR | KOB |
| 19. | ZH22Z04000 | [7] | HYD CONNECTOR | KOB1/4"PTx1/4"PFx37mm Long |
| 20. | ZH32Z04000 | [3] | ELBOW | KOB90° -- (1/4" PT - 1/4" PT), (Incls. O-Ring ZD12P01100) |
| 21. | 2432T1264 | [4] | CLAMP | KOB |
| 22. | 2432T2417 | [6] | CLAMP | KOB |
| 23. | 2432T1476 | [1] | CLAMP | KOB |
| 24. | 2416T3655 | [2] | CLAMP | KOB |
| 25. | 2416T17769 | [2] | BRACKET | KOB |
| 26. | ZN18C06005 | [2] | NUT | KOBM06x1.0mm |
| 27. | 2419P1852 | [1] | PIN | KOB |
| 28. | 2419P1853 | [1] | PIN | KOB |
| 29. | 2419P2106 | [1] | PIN | KOB |
| 30. | 2416T9975 | [2] | COLLAR | KOB |
| 31. | ZS18C20160 | [3] | SCREW,Hex, M20 x 160mm | KOBM20x2.50x160mm |
| 32. | ZS18C20035 | [2] | SCREW,Hex, M20 x 35mm | KOBM20x2.50x35mm |
| 33. | ZS18C12045 | [4] | SCREW,Hex, M12 x 45mm | KOBM12x1.75x45mm |
| 34. | ZS18C12050 | [2] | SCREW,Hex, M12 x 50mm | KOBM12x1.75x50mm |
| 35. | ZS18C12065 | [6] | SCREW,Hex, M12 x 65mm | KOBM12x1.75x65mm |
| 36. | ZS18C08012 | [6] | SCREW,Hex, M8 x 12mm | KOBM08x1.25x12mm |
| 37. | 2420T2747D5 | [2] | SHIM,102mm ID x 170mm OD x 3.2mm Thk | KOBID 102 x OD 170 x Th 3.2mm |
| 38. | ZS18C12075 | [24] | SCREW,Hex, M12 x 75mm | KOBM12x1.75x75mm |
| 39. | ZN18C12010 | [2] | NUT | KOBM12x1.75mm |
| 40. | ZN18C20016 | [6] | NUT | KOBM20x2.5mm |
| 41. | ZW16H12000 | [40] | WASHER | KOBID 13 x OD 26 x Th 3.2mm |
| 42. | ZW16H08000 | [6] | WASHER | KOBID 08 x OD 18 x Th 3.2mm |
| 43. | ZW26X06000 | [2] | LOCK WASHER | KOBID 06 x OD 07 x Th 1.5mm |
| 44. | 2420T2747D2 | [2] | SHIM,102mm ID x 170mm OD x 1.2mm Thk | KOBID 102 x OD 170 x Th 1.2mm |
| 45. | 2432T2958 | [2] | CLAMP | KOB |
| 46. | ZD12P03400 | [18] | O-RING,0.139" Thk x 1.296" ID, -219, Cl 6, 90 Duro | KOBID 33.70 ± 0.33 x OD 40mm |
| 48. | ZG91S02000 | [7] | LUBE NIPPLE,1/8" NPT x 1/8" NPT | KOB1/8" PT -- Straight |
| 49. | 2420T6798 | [1] | SLOTTED NUT | KOBCastle -- M64 |
| 50. | ZP15D10100 | [1] | COTTER PIN | KOBOD 10 x 100mm Long |
| 51. | R16T0152D14 | [1] | WASHER | KOBFlat -- ID 65 x OD 160 x Th 12.0mm |
| 52. | ZX58S16080 | [4] | FLEXIBLE HOSE | KOB |
| 53. | 2419T4391 | [1] | PIN | KOB |
| 54. | 2419T5793 | [2] | PIN | KOB |
| 55. | ZX28S16160 | [4] | FLEXIBLE HOSE | KOB |
| 56. | 2418T13646 | [1] | PLATE | KOB |
| 57. | ZS18C20060 | [2] | SCREW,Hex, M20 x 60mm | KOBM20x2.50x60mm |
| 58. | ZW16H20000 | [2] | WASHER | KOBID 21 x OD 40 x Th 4.5mm |
| 59. | B16T0442D13 | [8] | SHIM,160mm OD x 92mm ID x 1.2mm Thk | KOBID 92 x OD 160 x Th 1.2mm |
| 60. | ZS23C12035 | [2] | SCREW,Hex Socket Head, M12 x 35mm | KOBM12x1.75x35mm |
| 61. | 2416T5904 | [1] | CLAMP | KOB |
| 62. | 2432Z290 | [7] | CLIP | KOBWire Ties -- 185mm Long Superseded by part number: PY01P01043D3 |
| 63. | ZS18C12090 | [2] | SCREW,Hex, M12 x 90mm | KOBM12x1.75x90mm |
| 64. | B16T0442D14 | [3] | SHIM,160mm OD x 92mm ID x 1.6mm Thk | KOBID 92 x OD 160 x Th 1.6mm |
| 65. | B16T0442D38 | [2] | SHIM,205mm OD x 102mm ID x 1.6mm Thk | KOBID 102 x OD 205 x Th 1.6mm |
| 66. | 2420T2747D15 | [2] | SHIM,102mm ID x 200mm OD x 0.9mm Thk | KOBID 102 x OD 200 x Th 0.9mm |
| 67. | 2420T2747D11 | [2] | SHIM,102mm ID x 200mm OD x 1.2mm Thk | KOBID 102 x OD 200 x Th 1.2mm |
| 68. | ZW16H20000 | [2] | WASHER | KOBID 21 x OD 40 x Th 4.5mm |
| 69. | 2418T17068 | [2] | PLATE | KOB |
| 70. | 2420T2747D12 | [2] | SHIM,102mm ID x 200mm OD x 2.3mm Thk | KOBID 102 x OD 170 x Th 2.3mm |
| 71. | B16T0442D15 | [2] | SHIM,160mm OD x 92mm ID x 2.3mm Thk | KOBID 92 x OD 160 x Th 2.3mm |
| 72. | 2420T2747D3 | [2] | SHIM,102mm ID x 170mm OD x 1.6mm Thk | KOBID 102 x OD 170 x Th 1.6mm |
| 73. | 2420T2747D4 | [2] | SHIM,102mm ID x 170mm OD x 2.3mm Thk | KOBID 102 x OD 170 x Th 2.3mm |
| 74. | ZE13X16000 | [24] | FLANGE | KOBClamp, Half -- (Incls. Capscrew & Lockwasher) |
| 75. | ZS23C12045 | [48] | SCREW,Hex Socket Head, M12 x 45mm | KOBM12x1.75x45mm Superseded by part number: ZS28C12045 |
| 76. | ZW26K12000 | [48] | LOCK WASHER | KOBID 12 x OD 17.8 x Th 2.5mm |
| 77. | 2416T13056 | [1] | BRACKET | KOB |
| 78. | ZS18C10020 | [1] | SCREW,Hex, M10 x 20mm | KOBM10x1.50x20mm |
| 79. | ZW16H10000 | [1] | WASHER | KOBID 11 x OD 24 x Th 3.2mm |
| 80. | ZG91V02000 | [1] | LUBE NIPPLE,67 Degree x 1/8" PT | KOB67° x 1/8" PT Superseded by part number: 72283072 |
| 81. | 2411T1947 | [1] | KIT, LABEL | |
| 81-1. | 2432Z460 | [10] | LABEL | |
