凯斯零件查询(FLX810) - FLEX-AIR APPLICATOR (10/03-8/09) (02-036) - BIN GROUP, DOUBLE BIN, LH, 50 CU. FT. Case Agriculture
广数供应链运营团队, 15 02月, 2025，浏览：
452 次
| Pos. |
Part No |
Qty |
Parts name |
Comments |
| 1. |
342478A1
|
[2] |
LATCH
|
BN
Swell
|
| 2. |
BN308146
|
[1] |
COVER
|
BN
Co-Ap, Lower
|
| 3. |
BN308147
|
[2] |
PIN
|
BN
Lower Cover Pivot
|
| 4. |
NS
|
[1] |
NOT SERVICED
|
BAS
Bin Group, LH, (50)
|
| 5. |
BN310860
|
[1] |
COVER
|
BN
Support W/M, LH
|
| 6. |
BN310862
|
[2] |
WASHER
|
BN
Co-Ap Bin
|
| 7. |
BN310863
|
[1] |
STRAP
|
BN
Formed, Co-Ap Cover
|
| 8. |
BN35859
|
[4] |
COVER
|
BN
Shaft Hole, Co-Ap Bin
|
| 9. |
BN50146
|
[2] |
WASHER,3/8", Stainless
|
BN
|
| 10. |
BN50212
|
[22] |
BOLT,1/4"-20 x 3/4", Stainless Steel
|
BN
|
| 11. |
BN50250
|
[2] |
BOLT,3/8"-16 x 3/4", Stainless Steel
|
BN
Superseded by part number: 113-2299
|
| 12. |
BN50254
|
[2] |
BOLT,3/8"-16 x 1", Stainless
|
BN
|
| 13. |
BN50759
|
[4] |
LOCK NUT,3/8"-16, Nylon, Stainless
|
BN
|
| 14. |
BN313961
|
[5] |
SCREW,Hex, 1/4" x 3/4", SST
|
BN
1/4" X 3/4", HH, STP, SS Superseded by part number: 87270117
|
| 15. |
BN55359
|
[22] |
LOCK NUT,1/4"-20, SS
|
BN
|
