| 1. |
BN22901
|
[1] |
COVER
|
BN
2" Cam Lever Superseded by part number: 34416022
|
| 2. |
BN54054
|
[2] |
TAPE
|
BN
Safety Walk 6 X 29
|
| 6. |
BN23452
|
[2] |
WASHER,13/32" x 1.25 " OD x 12 GA, SS
|
BN
|
| 8. |
87266479
|
[1] |
CONTAINER
|
BN
Bin, LH Co-Ap-(50)
|
| 9. |
87265914
|
[1] |
COVER
|
BN
Co-Ap Bin(50)
|
| 10. |
BN312897
|
[1] |
SCREEN
|
TYR
W/M, Coap, 50
|
| 11. |
BN309335
|
[1] |
GASKET
|
BN
2" Ansi Flange, EPDM
|
| 12. |
BN309336
|
[1] |
HYDRAULIC VALVE
|
BN
2" Fp, Ansi Flange
|
| 13. |
BN309337
|
[1] |
LATCH
|
BN
Flexible Draw
|
| 14. |
BN309338
|
[1] |
PIN
|
BN
5/8 With Shoulder
|
| 15. |
87265979
|
[1] |
WINDOW
|
BN
5.5 x 5.5, Supplemental Bin
|
| 16. |
BN310264
|
[3] |
SCREW,#10 - 24 x 1 1/4", SST
|
BN
10-24 X 1-1/4", BSH, SS
|
| 17. |
BN310265
|
[3] |
WASHER
|
BN
10, Stainless Steel
|
| 18. |
BN310266
|
[3] |
BHD LOCK NUT,#10-24, Nylon, Stainless Steel
|
BN
|
| 19. |
BN310267
|
[1] |
WASHER,5/8", Stainless Steel
|
BN
|
| 20. |
BN35705
|
[1] |
BEARING HOUSING
|
BN
Valmar - HSG, LH
|
| 21. |
BN35706
|
[1] |
BEARING HOUSING
|
BN
Valmar - HSG, RH
|
| 22. |
BN35707
|
[2] |
BEARING CAP
|
BN
Valmar - Latch, Stainless Steel
|
| 23. |
87266476
|
[2] |
HINGE
|
BN
Co-Ap Cover (50)
|
| 24. |
87265978
|
[1] |
WINDOW
|
BN
Co-Ap Bin
|
| 25. |
BN50142
|
[13] |
WASHER,5/16", Stainless Steel
|
BN
|
| 26. |
BN50232
|
[4] |
BOLT,5/16"-18 x 1.00", Stainless Steel
|
BN
|
| 27. |
BN50234
|
[2] |
BOLT,5/16"-18 X 1-1/4", Stainless Steel
|
BN
|
| 28. |
BN50254
|
[2] |
BOLT,3/8"-16 x 1", Stainless
|
BN
|
| 29. |
BN50258
|
[2] |
BOLT,3/8"-16 X 1.25", Stainless
|
BN
|
| 30. |
BN50648
|
[4] |
BOLT,5/8"-11 X 2.00", Stainless Steel
|
BN
Superseded by part number: 16910161
|
| 31. |
BN50759
|
[4] |
LOCK NUT,3/8"-16, Nylon, Stainless
|
BN
|
| 32. |
BN55216
|
[4] |
ROLL PIN
|
BN
5/32 X 1 1/2, SS Superseded by part number: 84204175
|
| 33. |
BN55361
|
[7] |
NUT,5/16"-18, Nylon, Stainless
|
BN
|
| 34. |
BN55365
|
[5] |
LOCK NUT,5/8"-11, Nylon, Stainless
|
BN
|
| 35. |
BN310648
|
[1] |
LIGHT
|
BN
See Fig 02-053
|
| 36. |
BN319646
|
[1] |
SENSOR
|
BN
Hopper Level
|
| 37. |
BN310644
|
[1] |
MOUNTING PLATE
|
BN
Bin Lights
|
| 38. |
BN50697
|
[4] |
BOLT,Hex, 1/4" - 20 x 1/2", SST
|
BN
|
| 39. |
BN55359
|
[4] |
LOCK NUT,1/4"-20, SS
|
BN
|
| 40. |
BN319230
|
[1] |
COVER
|
BN
Wire, HOP. Sensor
|
| 41. |
BN310002
|
[1] |
BUMPER
|
BN
1.00 OD x 1.0 H
|
