神钢零件查询(MD400LC) - EXCAVATOR BTW YS0101 - YS0200 (1/80-12/06) (09-004) - VALVE ASSY SHUTTLE/ P.N. 2436R734F1 Kobelco
广数供应链运营团队, 15 02月, 2025，浏览：
869 次
| Pos. | Part No | Qty | Parts name | Comments |
|---|
| . . | 2436R754F1 | [1] | VALVE ASSY, SHUTTLE CONSITS OF THE FOLLOWING PARTS | |
| 1. | NNS | [1] | BODY | |
| 2. | NNS | [1] | SPOOL | |
| 3. | NNS | [1] | 8POOL | |
| 4. | 2436U94S16 | [2] | PLUG | |
| 5. | 2436U1757S25 | [1] | SPRING | KOBPLUG |
| 6. | 2436R1094S17 | [1] | KIT, ADJUST | |
| 7. | 2436R734S7 | [1] | SPRING | |
| 8. | 2436U946S19 | [1] | SPRING | |
| 9. | 2436U1027S68 | [2] | O-RING | KOBO-RING Superseded by part number: ZD12P00800 |
| 10. | 2483U28389 | [1] | O-RING | |
| 11. | 2436U1027S212 | [1] | O-RING | KOB Superseded by part number: ZD12P01000 |
| 12. | ZD12P00700 | [10] | O-RING,1.6mm Thk x 6.8mm ID, 90 Duro | KOBO-Ring -- ID 06.80 ± 0.16 x OD 10mm |
| 13. | NNS | [1] | BALL | |
