凯斯零件查询(FLX810) - FLEX-AIR APPLICATOR (10/03-8/09) (04-014) - BOOM GROUP, 2.5”, 60’, OUTER, RH Case Agriculture
广数供应链运营团队, 15 02月, 2025，浏览：
1006 次
| Pos. |
Part No |
Qty |
Parts name |
Comments |
| 1. |
BN10465
|
[5] |
NIPPLE, LUBE,1/4"-28 st
|
BN
NIPPLE
|
| 2. |
87310597
|
[2] |
WASHER,0.44" ID x 1" OD x 0.08" Thk
|
BN
|
| 3. |
87564720
|
[4] |
WASHER,0.78" ID x 1.25" OD x 0.07" Thk
|
BN
|
| 4. |
BN50594
|
[1] |
BOLT,1/2"-13 x 1.75", Stainless
|
BN
|
| 5. |
BN50601
|
[2] |
PIN, SPLIT (COTTER)
|
BN
PIN, COTTER 3/16 X 2"
|
| 6. |
87343970
|
[1] |
NUT,3/8"-16, G8, DOR
|
A
|
| 7. |
BN52335
|
[4] |
E-RING,1"
|
BN
E-Type, 1", SST
|
| 8. |
BN52336
|
[2] |
CLIP
|
BN
E-Type, 3/4", SST
|
| 9. |
BN55363
|
[3] |
LOCK NUT,1/2"-13, Nylon, Stainless
|
BN
|
| 10. |
BN55369
|
[1] |
BOLT,1/2"-13 x 3", Stainless
|
BN
|
| 11. |
BN55372
|
[1] |
BOLT,1/2"-13 x 3.25", Stainless
|
BN
|
| 12. |
87310189
|
[1] |
BOLT,3/8"-16 x 3-1/2", G5
|
BN
|
| 13. |
87271751
|
[4] |
CLAMP
|
BN
Hi-Torque
|
| 14. |
BN67861
|
[2] |
PIN,26.42mm OD x 50.8mm L
|
BN
Mid Boom Fold
|
| 16. |
BN325678
|
[4] |
DEFLECTOR
|
TYR
2.5, RH
|
| 17. |
BN69195
|
[1] |
BOOM
|
TYR
MID, 2.50, RH
|
| 18. |
BN69197
|
[1] |
BOOM
|
TYR
Outer, 2.50, RH
|
| 19. |
BN69290
|
[1] |
LINK
|
BN
Breakaway
|
| 20. |
BN69294
|
[1] |
ROLLER
|
BN
Breakaway
|
| 21. |
BN69295
|
[1] |
SPACER
|
BN
Breakaway
|
| 22. |
BN69452
|
[14] |
SPRING
|
BN
Disc-1.5 X .515 X .07
|
| 23. |
87265964
|
[1] |
LINKAGE
|
BN
Boom Fold, RH
|
| 24. |
87265965
|
[1] |
LINKAGE
|
BN
Boom Fold, LH
|
| 25. |
BN69466
|
[1] |
SPACER
|
BN
Boom Fold Links
|
| 26. |
BN69467
|
[1] |
STOP
|
BN
breakaway
|
| 27. |
BN69745
|
[1] |
PIN,20.07mm OD x 146.05mm L
|
BN
Outer Boom Fold
|
| 28. |
BN25232
|
[2] |
BUMPER
|
BN
1.56" Dia - Urethane
|
| 29. |
BN69951
|
[5] |
CAP
|
BN
Grease
|
