神钢零件查询(MD400LC) - EXCAVATOR BTW YS0101 - YS0200 (1/80-12/06) (09-024) - VALVE ASSY, COUNTER-BALLANCE Kobelco
广数供应链运营团队, 15 02月, 2025，浏览：
353 次
| Pos. | Part No | Qty | Parts name | Comments |
|---|
| . . | 2436U856F2 | [1] | VALVE, COUNTERBLANCE CONSITS OF THE FOLLOWING PARTS | VALVE, COUNTERBLANCE CONSITS OF THE FOLLOWING PARTS |
| 1. | 2436U856S1 | [1] | BODY | |
| 2. | 2436U856S2 | [1] | SPOOL | |
| 3. | 2436U856S3 | [2] | PLUNGER | |
| 4. | 2436U856S4 | [2] | SPOOL | |
| 5. | 2436U856S5 | [2] | COVER | COVER |
| 6. | 2436U856S6 | [2] | RETAINER | |
| 7. | 2436U856S7 | [1] | ORIFICE | |
| 8. | 2436U856S8 | [2] | RETAINER | KOB |
| 9. | 2436U856S9 | [3] | PLUG | |
| 10. | 2436U1000S17 | [13] | PLUG | |
| 11. | 2436U1078S12 | [3] | PLUG | |
| 12. | 2436U856S12 | [8] | CAPSCREW | |
| 13. | 2436U856S13 | [6] | CAPSCREW | |
| 14. | ZD12P00700 | [4] | O-RING,1.6mm Thk x 6.8mm ID, 90 Duro | KOBO-Ring -- ID 06.80 ± 0.16 x OD 10mm |
| 15. | ZD12P00800 | [3] | O-RING,1.9mm Thk x 7.8mm ID, 90 Duro | KOBID 7.8mm x OD 9.7mm |
| 16. | ZD12P01200 | [3] | O-RING | KOBID 11.80 ± 0.19 x OD 16mm |
| 17. | ZD12P02000 | [2] | O-RING,2.4mm Thk x 19.8mm ID, 90 Duro | KOBID 19.80 ± 0.22 x OD 24mm |
| 18. | ZD12G03000 | [2] | O-RING,29.40mm ID x 35.60mm OD x 3.10mm | KOBID 29.4 ± 0.29 x OD 35mm |
| 19. | ZD12G05000 | [4] | O-RING,49.40mm ID x 55.60mm OD x 3.10mm | KOBID 49.40 ± 0.45 x OD 55mm |
| 20. | 2436U856S20 | [1] | SPRING | |
| 21. | 2436U856S21 | [2] | SPRING | |
| 22. | 2436U856S22 | [2] | SPRING | |
| 23. | 2436U856S23 | [1] | BALL | |
| 24. | 2436U856S24 | [2] | VALVE PRESSURE RELIE | KOB |
| 26. | 2436U856S26 | [1] | ORIFICE | |
| 27. | 2436U856S27 | [2] | PLATE | |
| 28. | 2436U856S28 | [2] | BALL | |
| 29. | 2436U1000S16 | [2] | SPRING | |
| 30. | 2436U850S30 | [2] | PLUG | |
| 31. | 2436U850S31 | [2] | RETAINER | |
