凯斯零件查询(FLX810) - FLEX-AIR APPLICATOR (10/03-8/09) (05-003) - TAILLIGHT GROUP, 46” 70’ 438A Case Agriculture
广数供应链运营团队, 15 02月, 2025，浏览：
386 次
| Pos. |
Part No |
Qty |
Parts name |
Comments |
| 1. |
NS
|
[1] |
NOT SERVICED
|
BAS
Taillight Assembly, Right Rear
|
| 3. |
BN50138
|
[8] |
WASHER,1/4", SS
|
BN
|
| 4. |
BN50212
|
[8] |
BOLT,1/4"-20 x 3/4", Stainless Steel
|
BN
|
| 5. |
BN85855
|
[2] |
GROMMET
|
BN
Lg, for 1/2" hose
|
| 6. |
BN55359
|
[8] |
LOCK NUT,1/4"-20, SS
|
BN
|
| 7. |
853765
|
[8] |
CLAMP,7.9mm, Coat, 10.3mm Bolt Hole, P Type
|
NH
|
| 8. |
BN9990114
|
[4] |
STRAP
|
BN
Ty Rap, "Eye Ty" 06205 3M
|
| 9. |
BN310266
|
[4] |
BHD LOCK NUT,#10-24, Nylon, Stainless Steel
|
BN
|
