凯斯零件查询(FLX810) - FLEX-AIR APPLICATOR (10/03-8/09) (07-007) - PUMP, PRESS COMP-60CC Case Agriculture
广数供应链运营团队, 15 02月, 2025，浏览：
740 次
| Pos. |
Part No |
Qty |
Parts name |
Comments |
| 0. |
86986504
|
[1] |
PUMP
|
BN
60CC, Pressure Compensated, Complete
|
| 1. |
87268471
|
[1] |
PIVOT PLATE
|
BN
Rotary Group A10V 60/R
|
| 2. |
87269704
|
[1] |
PISTON
|
BN
Control A10V
|
| 3. |
87269705
|
[1] |
PISTON ROD
|
BN
A10V 45/50X
|
| 4. |
87269706
|
[1] |
PUMP
|
BN
Housing A10VO
|
| 6. |
87269707
|
[1] |
PLATE
|
BN
Port, A10V
|
| 7. |
87269708
|
[1] |
PLATE
|
BN
Swash, A10V
|
| 8. |
87269709
|
[1] |
SHAFT
|
BN
Drive, A10V
|
| 9. |
87269710
|
[1] |
PLUG
|
BN
Screw, A10 Series
|
| 10. |
87269711
|
[1] |
SPRING
|
BN
|
| 12. |
87269712
|
[1] |
SHIM
|
BN
A10V
|
| 15. |
87269713
|
[1] |
TAPERED BEARING
|
BN
Tapered Roller 63 Superseded by part number: 86576989
|
| 16. |
87269714
|
[1] |
TAPERED BEARING
|
BN
Tapered Roller Superseded by part number: 81864433
|
| 17. |
87269715
|
[1] |
CRADLE
|
BN
Shell A10V R
|
| 18. |
87269716
|
[1] |
CRADLE
|
BN
Shell A10V L
|
| 20. |
87269717
|
[1] |
SEAL
|
BN
Shaft, Baft SL1AF
|
| 21. |
87269718
|
[1] |
O-RING,2.5mm Thk x 125mm ID
|
BN
125 X 2, 5 Superseded by part number: 8602862
|
| 22. |
87269719
|
[1] |
O-RING,23.7MM ID x 2.8MM Width
|
BN
23, 7 X 2, 8
|
| 24. |
87269720
|
[1] |
O-RING
|
BN
|
| 25. |
87269721
|
[1] |
LOCKING RING
|
BN
Safety
|
| 27. |
87269722
|
[1] |
SCREW,Skt, M14
|
BN
Socket, M14 x 45
|
| 29. |
87269723
|
[1] |
LOCKING RING
|
BN
Stop, A10V 60
|
| 31. |
87269724
|
[1] |
STOP
|
BN
Plug
|
| 33. |
87269725
|
[1] |
DOWEL
|
BN
PI6 M6 x 18
|
| 34. |
87269726
|
[1] |
PLUG
|
BN
N 02.106-7/8 UNF 2A
|
| 37. |
87269727
|
[1] |
SCREW,CSK, M5 x 16mm
|
BN
Countersunk, M5 X 16
|
| 38. |
87269728
|
[1] |
FIP KIT
|
BN
Rotary Group A10V 60
|
| 39. |
87269729
|
[1] |
PLATE
|
BN
Distributor
|
