神钢零件查询(MD400LC) - EXCAVATOR BTW YS0101 - YS0200 (1/80-12/06) (09-055[02]) - PUMP ASSY, HYDRAULIC Kobelco
广数供应链运营团队, 15 02月, 2025，浏览：
146 次
| Pos. | Part No | Qty | Parts name | Comments |
|---|
| . . | 2441U721F1, F2, F3 | [1] | PUMP ASSY, HYDRAULIC CONSISTS OF THE FOLLOWING PARTS | |
| 2. | 2441U721S2 | [1] | HOUSING | |
| 3. | 2441U721S3 | [1] | PLATE | KOB |
| 4. | 24100U448S16 | [2] | PLUG | KOB |
| 5. | 2436U1691S29 | [1] | PLUG | KOB |
| 6. | 2441U658S3 | [2] | PLUG | PLUG |
| 7. | 2441U658S4 | [2] | NUT | KOB |
| 8. | ZD11P01600 | [2] | O-RING | KOBID 15.80 ± 0.20 x OD 20.6mm |
| 9. | ZS73C12055 | [1] | SETSCREW | |
| 10. | ZS73C12070 | [1] | SETSCREW | |
| 11. | 2441U721S11 | [1] | SHAFT | KOB |
| 12. | 2441U721S12 | [1] | BLOCK | KOB |
| 13. | 2441U721S13 | [1] | PIN | |
| 14. | 2441U721S14 | [7] | PISTON | KOB |
| 15. | 2441U721S15 | [7] | PISTON RING | KOB |
| 16. | 2441U721S16 | [1] | RETAINER | KOB |
| 17. | 2441U721S17 | [4] | SPRING | KOB |
| 18. | 2441U404S206 | [1] | PLATE | PLATE |
| 19. | 2441U404S221 | [14] | SCREW | KOB |
| 20. | 2441U721S20 | [1] | BEARING | KOB Superseded by part number: 2441U184S234 |
| 21. | 2441U721S21 | [1] | BEARING | BEARING |
| 22. | 2441U721S22 | [1] | PIECE | PIECE |
| 23. | 2441U721S23 | [1] | PIECE | |
| 24. | 2441U721S24 | [1] | NUT | KOB |
| 26. | 2441U721S26 | [1] | CASE | CASE |
| 27. | 2441U659S21 | [1] | OIL SEAL | KOB Superseded by part number: 2441U187S17 |
| 28. | 2441U721S28 | [1] | RING | KOB |
| 29. | 2441U721S29 | [1] | O-RING | O-RING |
| 30. | 2441U659S26 | [1] | KEY | KOB |
| 31. | 2441U721S31 | [1] | SHIM | KOB |
| 32. | 2441U721S32 | [1] | SHIM | KOB |
| 33. | 2441U721S35 | [1] | SHIM | KOB |
| 34. | 2441U721S34 | [1] | SHIM | KOB |
| 35. | 2441U721S35 | [1] | SHIM | KOB |
| 36. | 2441U721S36 | [1] | SHIM | |
| 37. | 2441U721S37 | [1] | SHIM | |
| 38. | 2436U1847F2 | [1] | HYDRAULIC VALVE | KOBSEE FIGURE (C.P.M) F2 & F3 ONLY |
| 39. | 2436U1847F1 | [1] | VALVE, CUT-OF SEE FIGURE (C.P.M) F1 ONLY | |
| 40. | 2436U1850F1 | [1] | X | KOBSEE FIGURE (C.P.M.) |
| 41. | 2436U1852F1 | [1] | SOLENOID VALVE | KOBSEE FIGURE (C.P.M) F1 & F2 ONLY |
| 42. | 2441U721S42 | [1] | BODY | BODY |
| 43. | 2441U721S43 | [1] | PACKING | KOB |
| 44. | 2441U721S44 | [1] | PLUNGER | KOB |
| 45. | 2441U721S45 | [1] | ROD | KOB |
| 46. | 2441U659S38 | [1] | ROD | KOB |
| 47. | 2441U721S47 | [2] | SPRING | |
| 48. | 2441U659S40 | [1] | RETAINER | RETAINER |
| 49. | 2441U659S41 | [1] | RETAINER | RETAINER |
| 50. | 2441U658S40 | [1] | RING PIEC | RING PIEC |
| 51. | 2441U659S43 | [1] | SETSCREW | |
| 52. | ZS23C12035 | [6] | SCREW,Hex Socket Head, M12 x 35mm | KOBM12x1.75x35mm |
| 53. | ZW22K06000 | [6] | LOCK WASHER | KOBID 06 x OD 10 x Th 1.5mm |
| 54. | 2441U658S46 | [2] | PIN | PIN |
| 55. | ZP26D04014 | [1] | ROLL PIN | KOBSPRING |
| 56. | ZS83C10012 | [1] | SET OF SCREWS | KOB |
| 57. | 24100U448S16 | [1] | PLUG | KOB |
| 58. | 2456U1691S33 | [2] | PLUG | |
| 59. | 2456U1692S28 | [2] | PLUG | |
| 60. | 2441U720S49 | [1] | PLUG | KOB |
| 61. | 2441U659S44 | [1] | RETAINER | KOB |
| 62. | 2441U659S45 | [2] | BUSHING | KOB |
| 63. | 2441U658SS5 | [1] | PISTON | |
| 64. | 2441U658S53 | [1] | BUSHING | |
| 65. | 2441U658S54 | [1] | RETAINER | KOB |
| 66. | 2456U1691S12 | [1] | RETAINER | |
| 67. | 2441U658S56 | [1] | SPRING | SPRING |
| 68. | 2441U658S57 | [1] | SPRING | SPRING |
| 69. | 2441U658S58 | [1] | COLLAR | COLLAR |
| 70. | 2436R749F1 | [1] | PLATE ASSY, F3 ONLY | |
| 71. | 2441U721S71 | [4] | CAPSCREW F3 ONLY | CAPSCREW F3 ONLY |
| . . | 2441U658R100 | [1] | REPAIR KIT REPAIR KIT CONSISTS OF REF 11 - 24, 26 - 37 | REPAIR KIT REPAIR KIT CONSISTS OF REF 11 - 24, 26 - 37 |
| . . | 2441U658R110 | [1] | REPAIR KIT | KOBREPAIR KIT CONSISTS OF REF 63 -69 |
