| . . | 24100J7834F1 | [1] | ARM ASSY, SEMI-LONG | |
| 2. | 2438U664F1 | [1] | BRACKET | KOBSEE FIGURE (C.P.M.) |
| 3. | 2406N708D1 | [1] | LINK, IDLER | LINK, IDLER |
| 4. | 2406N708D2 | [1] | LINK, IDLER | LINK, IDLER |
| 5. | 2406N1037F1 | [1] | LINK, BUCKET | LINK, BUCKET |
| 5-1. | 2406N1037 | [1] | LINK, BUCKET | |
| 5-7. | 2405P311 | [2] | BUSHING | KOBID 100 x OD 120 x 110mm Long, Flange OD 190 |
| 5-8. | 2405T921 | [2] | BUSHING | KOBID 100 x OD 120 x 108mm Long |
| 5-10. | 2445R138D9 | [4] | SEAL,100mm ID x 120mm OD x 4mm Thk | KOBDust -- ID 100 x OD 120 x Th 4mm |
| 6. | 2419P2652 | [1] | PIN,110mm OD x 315mm L | KOBOD 110 x 315mm Long |
| 7. | 2419P2198 | [1] | PIN,100mm OD x 305mm L | KOBOD 100 x 305mm Long |
| 8. | 2419P2200 | [1] | PIN | KOB |
| 9. | 2419P2420 | [1] | PIN | PIN |
| 10. | 2418N2702 | [1] | TUBE | TUBE |
| 11. | 2418N2703 | [1] | TUBE | TUBE |
| 12. | ZX58N16200 | [2] | FLEXIBLE HOSE | KOB2000mm Long (78-3/4 in) |
| 13. | 2416P6934 | [1] | U-BRACKET | KOB |
| 14. | 2418T3887D1 | [4] | PLATE | KOB |
| 15. | 2432P824 | [12] | CLAMP | KOB |
| 16. | 2432T1213D2 | [2] | CLAMP | KOB |
| 17. | ZD12P03400 | [2] | O-RING,0.139" Thk x 1.296" ID, -219, Cl 6, 90 Duro | KOBID 33.70 ± 0.33 x OD 40mm |
| 18. | ZS18C10025 | [8] | SCREW,Hex, M10 x 25mm | KOBM10x1.50x25mm |
| 19. | ZS18C12025 | [8] | SCREW,Hex, M12 x 25mm | KOBM12x1.75x25mm |
| 20. | ZS18C12075 | [9] | SCREW,Hex, M12 x 75mm | KOBM12x1.75x75mm |
| 21. | ZS18C12100 | [12] | SCREW,Hex, M12 x 100mm | KOBM12x1.75x100mm |
| 23. | ZN18C12010 | [25] | NUT | KOBM12x1.75mm |
| 24. | ZW16H12000 | [9] | WASHER | KOBID 13 x OD 26 x Th 3.2mm |
| 25. | ZG91S02000 | [10] | LUBE NIPPLE,1/8" NPT x 1/8" NPT | KOB1/8" PT -- Straight |
| 26. | ZG91U02000 | [1] | LUBE NIPPLE | KOB90° x 1/8" PT |
| 27. | 2420T2747D2 | [1] | SHIM,102mm ID x 170mm OD x 1.2mm Thk | KOBID 102 x OD 170 x Th 1.2mm |
| 28. | 2420T2747D3 | [1] | SHIM,102mm ID x 170mm OD x 1.6mm Thk | KOBID 102 x OD 170 x Th 1.6mm |
| 29. | 2420T2747D4 | [1] | SHIM,102mm ID x 170mm OD x 2.3mm Thk | KOBID 102 x OD 170 x Th 2.3mm |
| 30. | 2420T2747D5 | [1] | SHIM,102mm ID x 170mm OD x 3.2mm Thk | KOBID 102 x OD 170 x Th 3.2mm |
| 31. | 2420T2747D7 | [1] | SHIM,112mm ID x 180mm OD x 1.2mm Thk | KOBID 112 x OD 180 x Th 1.2mm |
| 32. | 2420T2747D8 | [1] | SHIM,112mm ID x 180mm OD x 1.6mm Thk | KOBID 112 x OD 180 x Th 1.6mm |
| 33. | 2420T2747D9 | [1] | SHIM,112mm ID x 180mm OD x 2.3mm Thk | KOBID 112 x OD 180 x Th 2.3mm |
| 34. | 2420T2747D10 | [1] | SHIM,112mm ID x 180mm OD x 3.2mm Thk | KOBID 112 x OD 180 x Th 3.2mm |
| 35. | ZD12P17500 | [4] | O-RING | KOB |
| 36. | 2420R349D190 | [1] | HOSE,6.35mm ID x 1900mm L | KOB1900mm Long (74-13/16 in) |
| 37. | 2420R349D240 | [1] | HOSE,2400.00 mm | KOB Superseded by part number: HX21E04240DX |
| 38. | 2420R349D210 | [1] | FLEXIBLE HOSE | KOB2100mm Long (82-11/16 in) |
| 39. | 2444T2032D2 | [1] | HYD CONNECTOR | KOBElbow, 90° -- 1/4" PF - 1/8" PT x 43mm Long |
| 40. | 2444T2032 | [2] | HYD CONNECTOR | KOBElbow, 90° -- 1/4" PF - 1/8" PT x 20mm Long |
| 41. | 2416T3655 | [1] | CLAMP | KOB |
| 42. | ZS18C08012 | [12] | SCREW,Hex, M8 x 12mm | KOBM08x1.25x12mm |
| 43. | ZW26X08000 | [12] | LOCK WASHER | KOBLock -- ID 08 x OD 15 x Th 2.0mm Superseded by part number: 83990583 |
| 44. | ZH22Z04000 | [3] | HYD CONNECTOR | KOB1/4"PTx1/4"PFx37mm Long |
| 45. | 2416T5904 | [1] | CLAMP | KOB |
| 46. | 2416T4333 | [4] | CLAMP | KOB |
| 47. | 2419P2206 | [2] | PIN | KOB |
| 48. | ZW16H10000 | [4] | WASHER | KOBID 11 x OD 24 x Th 3.2mm |
| 49. | 2411X1001F1 | [1] | ARM | |
| 49-30. | 2405T919 | [2] | BUSHING | KOB |
| 49-31. | 2405P307 | [2] | BUSHING | KOBID 100 x OD 120 x 110mm Long, Flange OD 190 Superseded by part number: 2405P311 |
| 49-32. | 2405T920 | [2] | BUSHING | KOBID 100 x OD 120 x 100mm Long Superseded by part number: 2405T1950 |
| 49-33. | 2418T9359 | [1] | SPACER | KOB |
| 49-34. | 2318T9360D1 | [1] | SPACER | |
| 49-35. | 2445R138D13 | [2] | RUBBER SEAL,120mm ID x 140mm OD x 4mm Thk | KOBDust -- ID 120 x OD 140 x Th 4mm |
| 49-36. | 2445R138D9 | [2] | SEAL,100mm ID x 120mm OD x 4mm Thk | KOBDust -- ID 100 x OD 120 x Th 4mm |
