现代零件查询R800LC-7A COWLING 2(LOW NOISE)EPC Hyundai
广数供应链运营团队, 15 02月, 2025，浏览：
715 次
| Pos. |
Part No |
Qty |
Parts name |
Comments |
| 5. |
72ND-54102
|
[1] |
SCREEN ASSY
|
|
| 5-1. |
72ND-54112
|
[1] |
SCREEN WA
|
|
| 5-2. |
71ND-58400
|
[1] |
SCREEN ASSY
|
|
| 5-21. |
71ND-58410
|
[1] |
SCREEN
|
|
| 5-22. |
71ND-58430
|
[1] |
SPONGE
|
|
| 5-23. |
71EM-51580
|
[4] |
CAP-STUD BOLT
|
|
| 5-3. |
72ND-54302
|
[1] |
SPONGE
|
|
| 5-4. |
71EM-51580
|
[16] |
CAP-STUD BOLT
|
|
| 5-5. |
71Q6-50025
|
[6] |
BOLT-W/WASHER
|
|
| 5-6. |
71ND-54310
|
[1] |
BRACKET WA
|
|
| 6. |
71ND-55110
|
[1] |
SCREEN-PUMP
|
|
| 6. |
71ND-65100
|
[1] |
SCREEN-PUMP
|
|
| 7. |
71ND-55210
|
[1] |
SCREEN-PUMP
|
|
| 8. |
71ND-55300
|
[1] |
SCREEN-PUMP
|
|
| 8. |
71ND-65300
|
[1] |
SCREEN-PUMP
|
|
| 9. |
71ND-55400
|
[1] |
SCREEN-PUMP
|
|
| 9. |
71ND-65400
|
[1] |
SCREEN-PUMP
|
|
| 12. |
72ND-55501
|
[1] |
HOOD-MCV
|
|
| 12-1. |
NO75-D1-0
|
[1] |
PLATE-UPPER
|
|
| 12-2. |
NO75-D2-0
|
[1] |
PLATE-LOWER
|
|
| 12-8. |
NON1-A12-0
|
[1] |
HANDLE
|
|
| 12-9. |
S681-190400
|
[2] |
GROMMET
|
|
| 12-10. |
S403-161002
|
[2] |
WASHER-PLAIN
|
|
| 12-11. |
S275-160002
|
[2] |
NUT-SELF LOCKING
|
|
| 13. |
71N8-55210
|
[1] |
BRACKET-MCV HOOD,LH
|
|
| 14. |
71ND-55600
|
[1] |
BRACKET-MCV HOOD,RH
|
|
| 15. |
S403-08200B
|
[1] |
WASHER-PLAIN
|
|
| 16. |
S501-080002
|
[1] |
PIN-SELF LOCKING
|
|
| 17. |
S491-080252
|
[1] |
PIN-CLEVIS
|
|
| 18. |
71N6-56301
|
[1] |
STAY-MCV HOOD
|
|
| 19. |
71Q6-50030
|
[24] |
BOLT-W/WASHER
|
|
| 20. |
71Q6-50045
|
[4] |
BOLT-W/WASHER
|
|
| 24. |
E231-0134
|
[4] |
SHIM(1.0T)
|
|
| 32. |
72ND-55910
|
[1] |
BRACKET
|
|
