| Pos. | Part No | Qty | Parts name | Comments |
|---|---|---|---|---|
| 1. | 206-8873 | [1] | RING-PISTON | |
| 2. | 239-5893 | [2] | BEARING-JOURNAL | |
| 3. | 211-2261 | [1] | BEARING-THRUST | |
| 4. | 227-2584 | [1] | COLLAR-THRUST | |
| 5. | 239-5871 | [1] | RING-SEAL | |
| 6. | 506-9036 | [1] | SPACER-BEARING | |
| 7. | 206-8875 | [4] | BOLT(7.9X12.8X27.9-MM) | |
| 8. | 206-8868 | [1] | SEAL-RING | |
| 9. | 4P-3818M | [3] | BOLT(M4X0.7X10-MM) | |
| M | METRIC PART | |||
