凯斯零件查询(FLX810) - FLEX-AIR APPLICATOR (10/03-8/09) (10-026) - TANK RINSE GROUP, FLEX-AIR®, 60’ & 70’ Case Agriculture
广数供应链运营团队, 15 02月, 2025，浏览：
794 次
| Pos. |
Part No |
Qty |
Parts name |
Comments |
| 1. |
BN24567
|
[1] |
CHECK VALVE
|
BN
1 1/4" NPT Superseded by part number: 84347992
|
| 2. |
435587A1
|
[1] |
ELBOW
|
FLX
1" Flange x 1" Hose Barb, Poly
|
| 3. |
BN303203
|
[1] |
CLAMP,1" Flange
|
BN
1Fl Superseded by part number: 406041A1
|
| 4. |
408350A1
|
[1] |
MANIFOLD GASKET
|
FLX
1" x 7/32" thick
|
| 5. |
BN306903
|
[1] |
MANIFOLD,1" Flange x 1" Male NPT, Poly
|
BN
STR 1" X 1" male Superseded by part number: 87502088
|
| 6. |
BN310058
|
[2] |
NOZZLE
|
BN
Rinse Superseded by part number: 51405177
|
| 7. |
BN310090
|
[2] |
PIPE
|
BN
SS, 3/4 SC 40 X 22.00
|
| 8. |
BN53476
|
[1] |
FITTING,1" Male NPT x 1" Hose Barb, Poly
|
BN
1" NPT x 1" Hose Barb, Poly Superseded by part number: 34308001
|
| 9. |
BN53820
|
[1] |
EPDM 1" ID x 92"
|
|
| 10. |
BN53821
|
[2] |
HOSE
|
BN
EPDM 1" ID x 100"
|
| 11. |
BN53866
|
[2] |
EPDM 3/4" ID X 76"
|
|
| 12. |
BN73562
|
[2] |
ELBOW,90 Degree Elbow, 3/4" Male NPT x 3/4" Hose Barb, Poly
|
BN
3/4" NPT x 3/4" Hose Barb, 90° Superseded by part number: 34306061
|
| 13. |
BN73572
|
[2] |
NIPPLE, LUBE
|
BN
NIPPLE 3/4-1/2, Poly Superseded by part number: 406147A1
|
| 14. |
BN73574
|
[2] |
COUPLING
|
BN
3/4" Poly
|
| 15. |
BN73629
|
[1] |
TEE
|
BN
1" Poly Pipe Superseded by part number: 34308005
|
| 16. |
BN73657
|
[2] |
FITTING,1-1/4" Male NPT x 1" Hose Barb, Poly
|
BN
1-1/4" NPT x 1" Hose Barb, Poly
|
| 17. |
BN73684
|
[2] |
ELBOW
|
BN
90° 1" MPT x 3/4" Barb
|
| 18. |
BN310447
|
[6] |
HOSE CLAMP
|
BN
#20, Stainless Steel
|
| 19. |
BN310446
|
[4] |
HOSE CLAMP
|
BN
#12, Stainless Steel
|
