凯斯零件查询(FLX810) - FLEX-AIR APPLICATOR (10/03-8/09) (10-033) - WET BOOM, 3.0”, REAR TUBE, 60’ Case Agriculture
广数供应链运营团队, 15 02月, 2025，浏览：
1018 次
| Pos. |
Part No |
Qty |
Parts name |
Comments |
| 1. |
BN24083
|
[2] |
MOUNTING PLATE
|
BN
7 GA HRS 3.0 x 5.75/2
|
| 2. |
BN301636
|
[1] |
BAR
|
BN
Spray Group, Extend, RH
|
| 3. |
BN301637
|
[1] |
BAR
|
BN
Spray Group, Extend, LH
|
| 4. |
BN50146
|
[8] |
WASHER,3/8", Stainless
|
BN
|
| 5. |
BN50212
|
[4] |
BOLT,1/4"-20 x 3/4", Stainless Steel
|
BN
|
| 6. |
BN53475
|
[2] |
ELBOW,90 Degree Elbow, 1" Male NPT x 1" Hose Barb, Poly
|
BN
1" NPT x 1" Hose Barb, Poly Superseded by part number: 84325034
|
| 7. |
BN53476
|
[4] |
FITTING,1" Male NPT x 1" Hose Barb, Poly
|
BN
1" NPT x 1" Hose Barb, Poly Superseded by part number: 34308001
|
| 8. |
87389559
|
[2] |
VALVE
|
CUR
Electric, 1" Ball Superseded by part number: 51402333
|
| 9. |
BN53756
|
[2] |
HOSE,42.00"
|
BN
|
| 10. |
BN55359
|
[4] |
LOCK NUT,1/4"-20, SS
|
BN
|
| 11. |
BN66856
|
[2] |
HOSE
|
BN
1" EPMD x 25.00"
|
| 12. |
BN15497
|
[4] |
CLAMP,76.2mm - 82.55mm
|
BN
3 1/4", SS, T-Bolt
|
| 13. |
BN68086
|
[4] |
CAP
|
BN
RND, Rubber,.25 ID x 1.00
|
| 14. |
BN65560
|
[4] |
TUBE
|
BN
Extension, 14.75
|
| 15. |
BN73629
|
[2] |
TEE
|
BN
1" Poly Pipe Superseded by part number: 34308005
|
| 16. |
BN73648
|
[2] |
NIPPLE
|
BN
1" Short Poly Pipe Superseded by part number: 87608458
|
| 17. |
BN310447
|
[10] |
HOSE CLAMP
|
BN
#20, Stainless Steel
|
| 18. |
BN68492
|
[4] |
U-BOLT
|
BN
3/8-16 UNC x 3, SS
|
| 19. |
BN50759
|
[4] |
LOCK NUT,3/8"-16, Nylon, Stainless
|
BN
|
