现代零件查询R800LC-7A LOWER ROLLER(#0068-)EPC Hyundai
广数供应链运营团队, 15 02月, 2025，浏览：
322 次
| Pos. |
Part No |
Qty |
Parts name |
Comments |
| . |
81ND-11050
|
[18] |
LOWER ROLLER
|
|
| . |
81ND-11010
|
[18] |
LOWER ROLLER
|
|
| . |
81QF-11051BG
|
[18] |
ROLLER-LOWER
|
|
| 1. |
81ND-11500
|
[1] |
SHEEL-ROLLER
|
|
| 1. |
81QF-11500
|
[1] |
SHEEL-ROLLER
|
|
| 2. |
81ND-11510
|
[1] |
SHAFT
|
|
| 2. |
81QF-11511
|
[1] |
SHAFT
|
|
| 3. |
81ND-11520
|
[2] |
COLLAR
|
|
| 4. |
81ND-11540
|
[2] |
BUSHING
|
|
| 5. |
81ND-11560
|
[2] |
FLOATING SEAL ASSY
|
|
| 5-1. |
81ND-11570
|
[2] |
F/SEAL
|
|
| 5-2. |
81ND-11580
|
[2] |
O-RING
|
|
| 6. |
81ND-11590
|
[2] |
O-RING(SHAFT)
|
|
| 7. |
81ND-11550
|
[2] |
PIN
|
|
| 8. |
81ND-11600
|
[1] |
BOLT-PLUG
|
|
