凯斯零件查询(FLX810) - FLEX-AIR APPLICATOR (10/03-8/09) (09-003) - FOAM TUBE GROUP, LH Case Agriculture
广数供应链运营团队, 15 02月, 2025，浏览：
330 次
| Pos. |
Part No |
Qty |
Parts name |
Comments |
| 1. |
NS
|
[1] |
NOT SERVICED
|
BAS
Chamber Group, Flex-Air, LH
|
| 2. |
87266747
|
[2] |
U-BOLT
|
CUR
1/4"-20 x 2.5 ID x 3"
|
| 3. |
BN324022
|
[1] |
HOSE CLAMP
|
BN
#8, Stainless Steel
|
| 4. |
86986173
|
[1] |
HOSE,0.50" ID x 200.00"
|
BN
|
| 5. |
86986175
|
[1] |
TUBE,0.375" DIA x 200" L
|
BN
Synflex, 3/8" X 200"
|
| 6. |
BN310447
|
[2] |
HOSE CLAMP
|
BN
#20, Stainless Steel
|
| 7. |
BN50138
|
[8] |
WASHER,1/4", SS
|
BN
|
| 8. |
BN55359
|
[12] |
LOCK NUT,1/4"-20, SS
|
BN
|
| 9. |
BN67054
|
[4] |
CLAMP
|
BN
1.315" OD
|
| 10. |
BN309483
|
[2] |
PLATE
|
BN
Single, Size 5
|
| 11. |
BN67050
|
[4] |
BOLT,1/4"-20 X 3.00", Stainless Steel
|
BN
|
| 12. |
86986166
|
[1] |
TUBE,69.10" L
|
TYR
Foam Drop
|
| 13. |
87266751
|
[1] |
HOSE
|
BN
1-1/4" X 262", Type K
|
| 14. |
BN310939
|
[1] |
ELBOW
|
BN
2" Hose Barb x 1-1/4" Hose Barb, 90 DEG, Poly
|
| 15. |
BN310449
|
[2] |
CLAMP,50mm - 65mm
|
BN
#32, Stainless Steel
|
| 16. |
87268528
|
[1] |
HOSE,2.00" ID x 26.00"
|
BN
Foam Drop
|
| 17. |
BN2403252
|
[1] |
BELL
|
BN
Foam Marker
|
| 18. |
BN325890
|
[3] |
CLAMP
|
BN
Vinyl Coated 1-9/16
|
| 19. |
BN50212
|
[1] |
BOLT,1/4"-20 x 3/4", Stainless Steel
|
BN
|
| 20. |
87035382
|
[2] |
CLAMP,30.2mm, Coat, 10.3mm Bolt Hole, P Type
|
GI
|
