凯斯零件查询(FLX810) - FLEX-AIR APPLICATOR (10/03-8/09) (09-006) - SOLENOID GROUP Case Agriculture
广数供应链运营团队, 15 02月, 2025，浏览：
506 次
| Pos. |
Part No |
Qty |
Parts name |
Comments |
| 1. |
BN307938
|
[2] |
VALVE
|
BN
Solenoid, 1/4 NPT
|
| 2. |
BN2399403
|
[2] |
ADAPTER
|
BN
1/4" MPT x 3/8" OD Tube, Push Lock Fitting
|
| 3. |
BN317051
|
[8] |
BOLT
|
BN
6-32 X 1.25"
|
| 4. |
BN317053
|
[8] |
LOCK NUT
|
BN
6-32 nylon lock
|
| 5. |
BN324009
|
[1] |
TEE
|
BN
All 1/2" HB, Poly
|
| 6. |
BN324022
|
[5] |
HOSE CLAMP
|
BN
#8, Stainless Steel
|
| 7. |
86986810
|
[1] |
FITTING
|
BN
Hosebarb, 3/8" X 1/4" NPT
|
| 8. |
86986177
|
[1] |
HOSE,0.38" ID x 100.00"
|
BN
Clear
|
| 9. |
86986808
|
[2] |
NIPPLE
|
BN
1/4" Short, Poly
|
| 10. |
86986807
|
[1] |
TEE
|
BN
1/4" Poly
|
| 11. |
86511189
|
[4] |
WASHER,0.16" ID x 0.38" OD x 0.05" Thk
|
PA
|
| 12. |
86986173
|
[1] |
HOSE,0.50" ID x 200.00"
|
BN
|
| . . |
87265139
|
[1] |
WIRE HARNESS
|
BN
RH Liquid Foamer
|
