现代零件查询R800LC-7A MAIN CONTROL VALVE(1/3, TYPE 2)EPC Hyundai
广数供应链运营团队, 15 02月, 2025，浏览：
996 次
| Pos. |
Part No |
Qty |
Parts name |
Comments |
| . |
31ND-16110
|
[1] |
MAIN CONTROL VALVE
|
|
| 20. |
XKAY-01573
|
[1] |
SPOOL ASSY
|
|
| 21. |
XKAY-01343
|
[2] |
SEAT-SPRING
|
|
| 22. |
XKAY-01344
|
[2] |
SPOOL ASSY
|
|
| 23. |
XKAY-01345
|
[2] |
SPRING
|
|
| 24. |
XKAY-01346
|
[2] |
O-RING
|
|
| 25. |
XKAY-01347
|
[2] |
PLUG
|
|
| 27. |
XKAY-01349
|
[2] |
SPRNG
|
|
| 28. |
XKAY-01574
|
[1] |
POPPET
|
|
| 37A. |
XKAY-01577
|
[2] |
O/R VALVE ASSY
|
|
| 37B. |
XKAY-01578
|
[4] |
O/R VALVE ASSY
|
|
| 38. |
XKAY-01481
|
[2] |
NEGACON VALVE ASSY
|
|
| 39. |
XKAY-01362
|
[1] |
PLUG ASSY
|
|
| 40. |
XKAY-01579
|
[1] |
POPPET
|
|
| 41. |
XKAY-01364
|
[1] |
SPRING
|
|
| 42. |
XKAY-01365
|
[1] |
PLUG
|
|
| 43. |
XKAY-01366
|
[1] |
O-RING
|
|
| 46. |
XKAY-01369
|
[1] |
PLUG ASSY
|
|
| N47. |
XKAY-01483
|
[2] |
PLUG ASSY
|
|
| N48. |
XKAY-01484
|
[5] |
PLUG ASSY
|
|
| N49. |
XKAY-01485
|
[19] |
PLUG ASSY
|
|
| N50. |
XKAY-01486
|
[5] |
PLUG ASSY
|
|
| N53. |
XKAY-01487
|
[10] |
BOLT-SOCKET HEAD
|
|
| 57. |
XKAY-01372
|
[1] |
POPPET
|
|
| 58A. |
XKAY-01580
|
[1] |
SERVICE RELIEF VALVE ASSY
|
|
| 58B. |
XKAY-01489
|
[1] |
SERVICE RELIEF VALVE ASSY
|
|
| N59. |
XKAY-01368
|
[4] |
O-RING
|
|
| N60. |
XKAY-01368
|
[3] |
O-RING
|
|
| N61. |
XKAY-01376
|
[10] |
O-RING
|
|
| N63. |
XKAY-00065
|
[1] |
PLUG
|
|
| N67. |
XKAY-01492
|
[4] |
BOLT-SOCKET HEAD
|
|
| N. |
@
|
[1] |
NOT SUPPLIED PARTS
|
|
