现代零件查询R800LC-7A MAIN CONTROL VALVE(2/3, TYPE 2)EPC Hyundai
广数供应链运营团队, 15 02月, 2025，浏览：
337 次
| Pos. |
Part No |
Qty |
Parts name |
Comments |
| . |
@
|
[1] |
MAIN CONTROL VALVE
|
|
| N1. |
XKAY-01561
|
[1] |
HOUSING-VALVE,LH
|
|
| 6. |
XKAY-01566
|
[1] |
SPOOL ASSY-TRAVEL
|
|
| 8. |
XKAY-01568
|
[1] |
SPOOL ASSY-ARM 1
|
|
| 9. |
XKAY-01569
|
[1] |
SPOOL ASSY-SERVICE
|
|
| 10. |
XKAY-01570
|
[1] |
SPOOL ASSY-BOOM 2
|
|
| 11. |
XKAY-01571
|
[1] |
SPOOL ASSY-SWING
|
|
| 12A. |
XKAY-01332
|
[5] |
CAP-SPOOL,A
|
|
| 13A. |
XKAY-01334
|
[5] |
FLANGE-SPOOL ,A
|
|
| N14. |
XKAY-01336
|
[10] |
O-RING
|
|
| 15. |
XKAY-01337
|
[1] |
POPPET
|
|
| 16. |
XKAY-01338
|
[1] |
SPRING
|
|
| 17. |
XKAY-01339
|
[1] |
SPACER
|
|
| 18. |
XKAY-01340
|
[1] |
O-RING
|
|
| 19. |
XKAY-01371
|
[1] |
RING-BACK UP
|
|
| 29. |
XKAY-01351
|
[3] |
POPPET
|
|
| 30. |
XKAY-01352
|
[1] |
POPPET
|
|
| 31. |
XKAY-01353
|
[6] |
SPRING
|
|
| 32. |
XKAY-01354
|
[4] |
FLANGE
|
|
| N33. |
XKAY-01355
|
[7] |
O-RING
|
|
| 34. |
XKAY-01575
|
[1] |
SWING PRIORITY ASSY
|
|
| 35. |
XKAY-01357
|
[2] |
H/D VALVE ASSY
|
|
| 36. |
XKAY-01576
|
[1] |
M/R VALVE ASSY
|
|
| 44. |
XKAY-01367
|
[1] |
FLANGE
|
|
| N51. |
XKAY-01497
|
[28] |
BOLT-SOCKET HEAD
|
|
| N52. |
XKAY-01498
|
[2] |
BOLT-SOCKET HEAD
|
|
| N56. |
XKAY-01501
|
[4] |
BOLT-SOCKET HEAD
|
|
| N60. |
XKAY-01375
|
[2] |
O-RING
|
|
| 64. |
XKAY-01581
|
[2] |
FLANGE
|
|
| N65. |
XKAY-01499
|
[16] |
BOLT-SOCKET HEAD
|
|
| N66. |
XKAY-01582
|
[2] |
O-RING
|
|
| N68. |
XKAY-01583
|
[8] |
BOLT-SOCKET HEAD
|
|
| N. |
@
|
[1] |
NOT SUPPLIED PARTS
|
|
