现代零件查询R800LC-7A MAIN CONTROL VALVE(3/3, TYPE 2)EPC Hyundai
广数供应链运营团队, 15 02月, 2025，浏览：
166 次
| Pos. |
Part No |
Qty |
Parts name |
Comments |
| . |
@
|
[1] |
MAIN CONTROL VALVE
|
|
| N2. |
XKAY-01562
|
[1] |
HOUSING-VALVE,RH
|
|
| 3. |
XKAY-01563
|
[1] |
SPOOL ASSY-ARM 2
|
|
| 4. |
XKAY-01564
|
[1] |
SPOOL ASSY-BUCKET
|
|
| 5. |
XKAY-01565
|
[1] |
SPOOL ASSY-BOOM 1
|
|
| 6. |
XKAY-01566
|
[1] |
SPOOL ASSY-TRAVEL
|
|
| 7. |
XKAY-01567
|
[1] |
SPOOL ASSY-TS
|
|
| 12A. |
XKAY-01332
|
[4] |
CAP-SPOOL,A
|
|
| 12B. |
XKAY-01333
|
[4] |
SPOOL CAP-B
|
|
| 13A. |
XKAY-01334
|
[4] |
FLANGE-SPOOL ,A
|
|
| 13B. |
XKAY-01335
|
[1] |
SPOOL FLANGE-B
|
|
| 14. |
XKAY-01336
|
[10] |
O-RING
|
|
| 15. |
XKAY-01337
|
[1] |
POPPET
|
|
| 16. |
XKAY-01338
|
[1] |
SPRING
|
|
| 17. |
XKAY-01339
|
[1] |
SPACER
|
|
| 18. |
XKAY-01340
|
[1] |
O-RING
|
|
| 19. |
XKAY-01371
|
[1] |
RING-BACK UP
|
|
| 26. |
XKAY-01348
|
[2] |
POPPET
|
|
| 27. |
XKAY-01349
|
[2] |
SPRNG
|
|
| 29. |
XKAY-01351
|
[3] |
POPPET
|
|
| 32. |
XKAY-01354
|
[3] |
FLANGE
|
|
| 33. |
XKAY-01355
|
[4] |
O-RING
|
|
| 35. |
XKAY-01357
|
[1] |
H/D VALVE ASSY
|
|
| 36. |
XKAY-01576
|
[1] |
M/R VALVE ASSY
|
|
| 44. |
XKAY-01367
|
[1] |
FLANGE
|
|
| 49. |
XKAY-01485
|
[2] |
PLUG ASSY
|
|
| 51. |
XKAY-01497
|
[24] |
BOLT-SOCKET HEAD
|
|
| 52. |
XKAY-01498
|
[2] |
BOLT-SOCKET HEAD
|
|
| 60. |
XKAY-01375
|
[2] |
O-RING
|
|
| 65. |
XKAY-01499
|
[12] |
BOLT-SOCKET HEAD
|
|
| N. |
@
|
[1] |
NOT SUPPLIED PARTS
|
|
