| . . | 2436U1345F1 | [1] | CONTROL VALVE | KOBCONSISTS OF THE FOLLOWING PARTS |
| . . | 2436U1345F2 | [1] | CONTROL VALVE | KOBVALVE ASSY, CONTROL, CONSISTS OF THE FOLLOWING PARTS |
| 1. | 2436U1345S1 | [1] | SPOOL | KOBF2 ONLY |
| 2. | 2436R847F1 | [2] | VALVE | KOBF2 ONLY |
| 101. | NSS | [1] | NOT SOLD SEPARAT | CONHOUSING |
| 102. | NSS | [1] | NOT SOLD SEPARAT | CONHOUSING |
| 103. | NSS | [2] | NOT SOLD SEPARAT | CONHOUSING |
| 105. | NSS | [1] | NOT SOLD SEPARAT | CONHOUSING |
| 106. | NSS | [1] | NOT SOLD SEPARAT | CONHOUSING |
| 152. | 2436U1165S152 | [34] | PLUG | KOB |
| 153. | 2436U1368S151 | [7] | PLUG | |
| 154. | 2436U1215S153 | [2] | PLUG | |
| 155. | 2436U1165S154 | [2] | PLUG | KOB |
| 156. | 2436U1165S157 | [3] | PLUG | KOB Superseded by part number: 2436U1265S157 |
| 158. | 2436U1207S155 | [15] | PLUG | KOBF1 ONLY |
| 161. | ZD12P05000 | [20] | O-RING | KOB |
| 162. | 2436U1345S162 | [13] | O-RING | KOB |
| 163. | ZD12P01500 | [11] | O-RING | KOBID 14.80 ± 0.20 x OD 19mm |
| 164. | ZD12P01800 | [2] | O-RING | KOBID 17.8mm x OD 20.2mm |
| 165. | ZD12P01400 | [2] | O-RING | KOBID 13.80 ± 0.19 x OD 18mm |
| 166. | ZD12P01100 | [7] | O-RING | KOBID 10.8mm x OD 13.2mm |
| 168. | ZD12P00800 | [15] | O-RING,1.9mm Thk x 7.8mm ID, 90 Duro | KOBID 7.8mm x OD 9.7mm, F1 Only |
| 201. | 2436U1345S201 | [4] | COVER | KOBSPRING |
| 202. | 2436U1345S202 | [5] | COVER SPOOL | COVER SPOOL |
| 206. | 2436U1345S206 | [1] | COVER | KOBBOOM |
| 251. | 2436U1345S251 | [5] | PLUG | KOB |
| 252. | 2436U1345S252 | [1] | PLUG | |
| 261. | ZD12G06500 | [5] | O-RING,64.40mm ID x 70.60mm OD x 3.10mm | KOBID 64.40 ± 0.57 x OD 70mm |
| 262. | ZD12P03400 | [1] | O-RING,0.139" Thk x 1.296" ID, -219, Cl 6, 90 Duro | KOBID 33.70 ± 0.33 x OD 40mm |
| 263. | ZD12G04500 | [5] | O-RING,44.40mm ID x 50.60mm OD x 3.10mm | KOBID 44.40 ± 0.41 x OD 50mm |
| 265. | ZD12P04200 | [5] | O-RING | KOBID 41.70 ± 0.39 x OD 48.7mm |
| 273. | ZS23C10025 | [20] | SCREW,Hex Socket Head, M10 x 25mm | KOBM10x1.50x25mm Superseded by part number: ZS28C10025 |
| 301. | 2436U1345S301 | [2] | SPOOL (PROPELLING) | SPOOL (PROPELLING) |
| 302. | 2436U1345S302 | [1] | SPOOL | KOB(ARM) Superseded by part number: 2436U2886S302 |
| 303. | 2436U1345S303 | [1] | SPOOL | KOB(BOOM) |
| 304. | 2436U1345S304 | [1] | SPOOL | KOB(BUCKET) |
| 308. | 2436R835F2 | [1] | VALVE | KOBSEE FIGURE 11-006 |
| 324. | 2436U1345S324 | [1] | SPRING | KOBSPRING |
| 326. | 2436U1345S326 | [2] | SPRING | KOB |
| 327. | 2436U1345S327 | [2] | SPRING | KOB |
| 332. | 2436U1345S332 | [10] | GASKET | KOB Superseded by part number: 2436U2670S332 |
| 335. | 2436U1345S335 | [5] | STOP | KOB |
| 336. | 2436U1345S336 | [5] | SCREW | KOBSPACER |
| 337. | 2436U1345S337 | [2] | ROD | KOB |
| 338. | 2436U1345S338 | [3] | ROD | KOB |
| 351. | 2436U1345S351 | [4] | ORIFICE | KOB Superseded by part number: 2436R885S13 |
| 355. | 2436U1345S355 | [1] | PISTON | KOBPISTON |
| 371. | 2436U1345S371 | [2] | SPRING | KOB |
| 372. | 2436U1345S372 | [5] | SPRING | KOB |
| 373. | 2436U1345S373 | [2] | SPRING | KOB |
| 374. | 2436U1345S374 | [3] | SPRING | KOB |
| 391. | 2436U1345S391 | [1] | SPOOL | KOBF1 ONLY |
| 392. | 2436U1345S392 | [2] | SPOOL | KOB |
| 393. | 2436U1345S393 | [1] | SPOOL | KOB |
| 394. | 2436U1345S394 | [1] | SPOOL | KOB |
| 511. | 2436U1345S511 | [8] | POPPET | KOB |
| 512. | 2483U172S19 | [6] | BALL | KOB |
| 513. | 2436U1345S513 | [1] | PLUNGER, F1 ONLY | |
| 514. | 2436U1345S514 | [1] | PLUNGER | KOBF2 ONLY |
| 521. | 2436U1345S521 | [7] | SPRING | KOB |
| 522. | 2436U1345S522 | [2] | SPRING | KOB |
| 541. | 2436U1265S542 | [3] | SEAT/SLOT | KOB |
| 543. | 2436U1345S543 | [2] | SEAT | KOB |
| 544. | 2436U1265S543 | [1] | SEAT/SLOT | KOB |
| 550. | 2436U585S651 | [1] | PLUG | KOB Superseded by part number: YT30V00009S153 |
| 551. | 2436U1744S852 | [13] | PLUG | KOB |
| 561. | ZD12P02900 | [13] | O-RING | KOBID 28.70 ± 0.29 x OD 35mm |
| 562. | ZD12P01000 | [1] | O-RING | KOBID 09.80 ± 0.17 x OD 13mm |
| 601. | 2436R848F1 | [2] | VALVE PRESSURE RELIE | KOBSEE FIGURE 11-010, F1 ONLY |
| 602. | 2436R845F2 | [2] | VALVE | KOBSEE FIGURE 11-008 |
| 603. | 2436R845F1 | [4] | VALVE | KOBF1 ONLY, SEE FIGURE 11-008 |
| 604. | 2436R846F1 | [2] | VALVE PRESSURE RELIE | KOBSEE FIGURE 11-008, F1 ONLY |
| 611. | 2436R844F1 | [2] | VALVE | KOBSEE FIGURE 11-007 |
| 612. | 2436U1345S612 | [1] | POPPET | POPPET |
| 751. | 2436U1345S751 | [1] | FLANGE | FLANGE |
| 761. | ZD12G04000 | [1] | O-RING,39.40mm ID x 45.60mm OD x 3.10mm | KOBID 39.40 ± 0.37 x OD 45mm |
| 762. | ZS23C14030 | [4] | SCREW,Hex Socket Head, M14 x 30mm | KOBM14x2.0x30mm |
| 971. | 2436U1345S971 | [2] | CAPSCREW | CAPSCREW |
| 972. | 2436U1345S972 | [2] | CAPSCREW | CAPSCREW |
| 973. | 2436U1345S973 | [1] | CAPSCREW | CAPSCREW |
| 974. | 2436U1345S974 | [1] | CAPSCREW | CAPSCREW |
| 991. | NSS | [1] | NOT SOLD SEPARAT | CONNAME PLATE |
| 992. | 2436U1345S992 | [1] | ORIFICE | KOB |
| . . | 2436U1345R100 | [1] | ARM | KOBARM BLOCK |
| . . | 2436U1345R200 | [1] | TRAVEL BLOCK | |
| . . | 2436U1345R300 | [1] | BOOM BLOCK | |
| . . | 2436U1345R400 | [1] | BUCKET BLOCK | |
| . . | 2436U1345R500 | [1] | A-END BLOCK | |
| . . | 2436U1345R600 | [1] | B-END BLOCK | |
| . . | 2436U1345R700 | [1] | REPAIR KIT NS ARM BLOCK | REPAIR KIT NS ARM BLOCK |
| . . | 2436U1345R800 | [1] | REPAIR KIT | KOBTRAVEL BLOCK |
| . . | 2436U1345R900 | [1] | REPAIR KIT NS BOOM BLOCK | REPAIR KIT NS BOOM BLOCK |
| . . | 2436U1345R1000 | [1] | BLOCK, VALVE BUCKET BLOCK | BLOCK, VALVE BUCKET BLOCK |
| . . | 2436U1345R1100 | [1] | REPAIR KIT | KOBA-END BLOCK |
| . . | 2436U1345R1200 | [1] | REPAIR KIT | KOBB-END BLOCK Superseded by part number: 2436U1345R1100 |
