凯斯零件查询(4300) - TITAN FLOATER (6/98-8/99) (10-008) - REAR FENDER, 66” Case Agriculture
广数供应链运营团队, 15 02月, 2025，浏览：
131 次
| Pos. |
Part No |
Qty |
Parts name |
Comments |
| 2. |
BN1470406C
|
[24] |
LOCK NUT
|
BN
NC 1/2-13 Flex Lock Superseded by part number: 231-4148
|
| 3. |
BN1913347C
|
[16] |
HH 1/2-13 X 1 3/4 N
|
|
| 4. |
BN1913337C
|
[8] |
BOLT
|
BN
HH 1/2-13 X 1-1/2 N Superseded by part number: 413-824
|
| 4A. |
BN2303146
|
[32] |
WASHER
|
BN
Flat 1/2
|
| 5. |
BN8205181
|
[2] |
FENDER
|
BN
Rear Titan Superseded by part number: 86986012
|
| 6. |
BN8205209
|
[2] |
MOUNTING PLATE
|
BN
Rear Fender
|
| 6A. |
BN8194088
|
[1] |
MUDFLAP
|
BN
Package
|
| 7. |
BN8091049
|
[2] |
SHEET METAL
|
TYR
Mud Flap Brace
|
| 8. |
BN8091048
|
[2] |
MOUNTING PLATE
|
BN
Mud Flap Superseded by part number: BN320352
|
| 9. |
BN310599
|
[2] |
MUDFLAP
|
BN
66"
|
| 10. |
BN2403263
|
[14] |
HH 3/8-16 X 1-1/2 SS
|
|
| 11. |
BN2294495
|
[14] |
LOCK NUT
|
BN
3/8-16 SS Flex
|
