| . . | 24100J11067F2 | [1] | REMOTE-CONTROL ASSY | |
| 1. | R18P0168D9 | [1] | HOSE \u00d825.4x380mm Long | HOSE Ø25.4x380mm Long |
| 2. | ZC15X03300 | [4] | CLIP | KOB |
| 3. | 2418P10004 | [1] | TUBE | KOB |
| 4. | ZA23F22012 | [1] | HYD CONNECTOR | KOB3/4"PF - M30x1.50 x 46mm Long |
| 5. | ZD12P02400 | [1] | O-RING | KOBID 23.70 ± 0.24 x OD 30mm |
| 6. | 2444Z2296 | [1] | HYD CONNECTOR | KOB |
| 7. | 2436U1171D31 | [1] | CHECK VALVE | KOB |
| 8. | 2444Z2892 | [1] | TEE | KOB(Incls. O-Ring ZD12P01400) |
| 9. | 2420R537D050 | [1] | HOSE,9.53mm ID x 500mm L | KOB |
| 10. | ZH22X06000 | [3] | HYD CONNECTOR | KOB(Incls. O-Ring ZD12P01400) |
| 11. | 2445R373F1 | [1] | ACCUMULATOR | KOB |
| 12. | 2444Z3134 | [1] | TEE | KOB1/4" PF x 40mm Long |
| 13. | 2444Z3336 | [2] | ELBOW | KOB |
| 14. | 2444Z3148 | [1] | HYD CONNECTOR | KOB |
| 15. | ZW22X10000 | [5] | LOCK WASHER | KOBID 10 x OD 18.4 x Th 2.5mm Superseded by part number: ZW26X10000 |
| 16. | 2444Z2359 | [2] | TEE | KOB3/8" PT (Incls. O-Ring ZD12P01400) |
| 17. | 2444Z2489 | [1] | HYD CONNECTOR | KOB |
| 18. | 2416T22061 | [1] | BRACKET | BRACKET |
| 19. | 2444Z3163 | [1] | HYD CONNECTOR | KOBCONNECTOR Superseded by part number: 2444Z3178D2 |
| 20. | 2444Z2546F1 | [1] | HYD CONNECTOR | KOB(WITH FILTER), Serial Range: YS0201-YS0258 |
| . . | 2444Z2546F1 | [2] | HYD CONNECTOR | KOB(WITH FILTER), Serial Range: YS0259-YS0401 |
| 21. | 2436R680F1 | [1] | VALVE PRESSURE RELIE | KOB |
| 22. | 2446R151F1 | [1] | ELEMENT | KOBFILTER, LINE Superseded by part number: 2446R183F1 |
| 22-1. | 2446R151S1 | [1] | HEAD | KOB |
| 22-2. | R36P0019 | [1] | HYDRAULIC OIL FILTER | KOBELEMENT |
| 22-3. | 45Z91D84 | [1] | O-RING | KOBID 56.74 ± 0.25 OD 63.80mm |
| 22-4. | 2446R151S4 | [1] | RING | KOBBACK-UP |
| 22-5. | 2446R151S5 | [1] | CASE | KOB |
| 23. | ZH32X06008 | [1] | 90 ELBOW,Male, 30 Degree Fl, PF 3/8" x PF 1/2", O-Ring | KOB90° -- 3/8"PFx1/2"PFx40mm Long (Same as ZD12P02400) |
| 24. | ZE72X04000 | [2] | PLUG | KOB(PF 1/4) (Incls. O-Ring ZD12P01100) |
| 25. | ZS13C08055 | [1] | SCREW | KOBM08x1.25x55mm Superseded by part number: ZS18C08055 |
| 26. | ZE72X06000 | [2] | PLUG | KOB3/8" PF, (Incls. O-Ring ZD12P01400) |
| 27. | 2436U1171D36 | [1] | CHECK VALVE | KOB |
| 28. | ZH31M08004 | [2] | ELBOW | KOB |
| 29. | 2420R349D030 | [1] | HOSE,300.00 mm | KOB |
| 30. | 2420R349D070 | [1] | HOSE,700.00 mm | KOB700mm Long (27-9/16 in) |
| 31. | 2444R974D6 | [1] | HOSE | KOB |
| 32. | 2444Z3331 | [1] | ELEC CONNECTOR | KOB |
| 33. | ZH22X04000 | [11] | HYD CONNECTOR,1/4" NPT x 1/4" NPT | KOB1/4"PFx36mm Long (Incls. O-Ring ZD12P01100), Serial Range: YS0201-YS0258 |
| . . | ZH22X04000 | [10] | HYD CONNECTOR,1/4" NPT x 1/4" NPT | KOB1/4"PFx36mm Long (Incls. O-Ring ZD12P01100), Serial Range: YS0259-YS0401 |
| 34. | 2444R963D26 | [1] | FLEXIBLE HOSE | KOB |
| 35. | 2444Z2432 | [1] | TEE | KOB1/4" PF x (2) 3/8" PF x 52mm Long (Incls. O-Ring ZD12P01400) |
| 36. | 2420R537D055 | [1] | HOSE ASSY.,9.60mm ID x 550mm L | KOB, Serial Range: YS0201-YS0202 |
| . . | 2420R537D060 | [1] | HOSE ASSY.,9.60mm ID x 600mm L | KOB, Start Serial: YS0203 |
| 37. | 2420R349D050 | [1] | HOSE,500.00 mm | KOB500mm Long (19-11/16 in) |
| 38. | 2420R349D150 | [1] | HOSE,6.35mm ID x 1500mm L | KOBPF 1/4 |
| 39. | 2420R349D100 | [2] | HOSE | KOB1000mm Long (39-3/8 in) Superseded by part number: HX21E04100DX |
| 40. | 2420R349D180 | [1] | HOSE,6.35mm ID x 1800mm L | KOB1800mm Long (70-7/8 in) |
| 41. | 2444R963D8 | [2] | HOSE | KOB |
| 42. | 2444Z2525 | [2] | HYD CONNECTOR | KOB1/4"PFx35mm Long (Incls. O-Ring ZD12P01100), Serial Range: YS0201-YS0207 Superseded by part number: 72217408 |
| . . | 2444Z2525 | [3] | HYD CONNECTOR | KOB1/4"PFx35mm Long (Incls. O-Ring ZD12P01100), Serial Range: YS0208-YS0401 Superseded by part number: 72217408 |
| 43. | ZH32X04000 | [9] | 90 ELBOW,Male, 30 Degree Fl, PF 1/4" x PF 1/4", O-Ring | KOBElbow, 90° -- PF 1/4, (Incls. O-Ring 237-6004), Serial Range: YS0201-YS0401 |
| . . | ZH32X04000 | [7] | 90 ELBOW,Male, 30 Degree Fl, PF 1/4" x PF 1/4", O-Ring | KOBElbow, 90° -- PF 1/4, (Incls. O-Ring 237-6004), Start Serial: YS0402 |
| 44. | 2444T2639F1 | [1] | HYD CONNECTOR | KOBCONNECTOR ASSY. (WITH FILTER), Serial Range: YS0259-YS0366 Superseded by part number: 2444Z2448F3 |
| . . | 2444T2639F1 | [2] | HYD CONNECTOR | KOBCONNECTOR ASSY. (WITH FILTER), Serial Range: YS0367-YS0401 Superseded by part number: 2444Z2448F3 |
| 46. | ZH31M08006 | [1] | ELBOW | KOB |
| 47. | 2444R963D25 | [1] | FLEXIBLE HOSE | KOBHOSE |
| 49. | 2420R349D040 | [1] | HOSE,6.35mm ID x 400mm L | KOB1/4" PF, 400mm Long (15-3/4 in) |
| 50. | ZX15K08130 | [1] | FLEXIBLE HOSE | KOB |
| 53. | ZX15K08055 | [1] | TUBE | TUBE |
| 54. | 2420R537D300 | [2] | HOSE,9.60mm ID x 3000mm L | KOB Superseded by part number: HX21E06300DX |
| 55. | 2444R963D7 | [1] | HOSE,6.35mm ID x 500mm L | KOB |
| 56. | 2444P1171D1 | [1] | CONNECTOR, Serial Range: YS0201-YS0253 | CONNECTOR, Serial Range: YS0201-YS0253 |
| 57. | 2444R941D11 | [1] | FLEXIBLE HOSE | KOB900mm Long (35-7/16 in) Superseded by part number: HX31E06090DX |
| 58. | ZH32X06000 | [5] | 90 ELBOW,Male, 30 Degree Fl, PF 3/8" x PF 3/8", O-Ring | KOBElbow, 90° -- (Incls. O-Ring ZD12P01400) Alternate O-Ring 237-6006 |
| 61. | 2444R941D21 | [1] | FLEXIBLE HOSE | KOB750mm Long (29-1/2 in) Superseded by part number: HX31E06075DX |
| 62. | ZX15K08013 | [1] | TUBE, NYLON | TUBE, NYLON |
| 64. | ZH51K08000 | [2] | TEE | KOB |
| 65. | 2420R349D145 | [1] | HOSE | KOB1450mm Long (57-5/64 in) Superseded by part number: HX21E04145DX |
| 66. | ZX15K08220 | [1] | FLEXIBLE HOSE | KOB |
| 69. | 2444R941D9 | [1] | FLEXIBLE HOSE | KOB800mm Long (31-1/2 in) |
| 71. | ZX15K08090 | [2] | FLEXIBLE HOSE | KOB |
| 72. | ZH21M08006 | [2] | HYD CONNECTOR | KOBCONNECTOR |
| 73. | 2444Z2345 | [1] | 90 ELBOW | KOB90° -- (Incls. O-Rings ZD12P01400 & ZD12P01800) |
| 74. | 2444Z2338 | [3] | 90 ELBOW | KOB90° -- (1/4" PFx3/8" PF), (Incls. O-Ring ZD12P01100) |
| 75. | ZH21M08004 | [7] | HYD CONNECTOR | KOBCONNECTOR |
| 76. | 2410T323 | [1] | BLOCK | KOB |
| 77. | ZS13C08040 | [2] | SCREW | KOBM08x1.25x40mm Superseded by part number: ZS18C08040 |
| 78. | ZW22X08000 | [7] | LOCK WASHER | KOBID 08 x OD 15.4 x Th 2.0mm Superseded by part number: 83990583 |
| 79. | 2420R349D085 | [2] | HOSE,6.35mm ID x 850mm L | KOB850mm Long (33-29/64 in) |
| 80. | 2444Z2461 | [2] | TEE | KOB1/4" PF (Incls. O-Ring ZD12P01100) |
| 82. | ZH52X04000 | [1] | TEE,30 Degree Fl, Male, PF 1/4" x 1/4" x 1/4", O-Ring | KOB1/4" PF (Incls. O-Ring 237-6004) |
| 83. | 2444Z2333 | [1] | TEE | KOB |
| 84. | 2420Z1188 | [3] | GROMMET | KOB |
| 85. | 2432Z290 | [20] | CLIP | KOBWire Ties -- 185mm Long Superseded by part number: PY01P01043D3 |
| 86. | 2444T2501D1 | [3] | TEE | KOB, Serial Range: YS0201-YS0253 |
| . . | 2444T2501D1 | [4] | TEE | KOB, Start Serial: YS0254 |
| 88. | ZX15K08034 | [1] | TUBE, NYLON | |
| 89. | 2444Z2448F1 | [1] | HYD CONNECTOR | KOB(WITH FILTER) |
| 90. | 2444Z2477F3 | [1] | HYD CONNECTOR | KOB(WITH FILTER) |
| 92. | 2444T3288 | [2] | 45 ELBOW | KOB45° -- (Incls. O-Ring ZD12P01100) |
| 95. | 2444T2501D2 | [1] | TEE | KOB, Serial Range: YS0201-YS0253 |
| 97. | 2436U1240F1 | [1] | SOLENOID VALVE | KOB |
| 98. | 2444Z2337 | [10] | HYD CONNECTOR | KOB(Incls. O-Ring ZD12P01100) |
| 99. | ZS13C08016 | [3] | SCREW | KOBM08x1.25x16mm Superseded by part number: ZS18C08016 |
| 101. | 2418T17907 | [1] | PLATE | |
| 102. | ZS13C10025 | [3] | CAPSCREW | KOBSCREW M10x1.50x25mm Superseded by part number: ZS18C10025 |
| 103. | 2406R256F1 | [2] | HANDLE | KOBHORN |
| 105. | ZX15K08120 | [1] | FLEXIBLE HOSE | KOB |
| 106. | 2444Z2336 | [3] | TEE | KOBTee -- 1/4"x3/8"x3/8"PF (Incls. O-Ring ZD12P01100), Serial Range: YS0201-YS0401 |
| . . | 2444Z2336 | [2] | TEE | KOBTee -- 1/4"x3/8"x3/8"PF (Incls. O-Ring ZD12P01100), Start Serial: YS0402 |
| 107. | 2420R349D260 | [1] | HOSE | KOB2600mm Long (102-23/64 in) Superseded by part number: HX21E04260DX |
| 108. | 2444R963D24 | [1] | HOSE | HOSE |
| 109. | ZX15K08230 | [1] | TUBE | KOB |
| 110. | 2444Z2447F5 | [1] | ELBOW ASSY | ELBOW ASSY |
| 111. | ZX15K08040 | [3] | PLASTIC-RUBBER TUBE | KOB |
| 112. | 2444Z2448F3 | [1] | HYD CONNECTOR | KOB(WITH FILTER), Serial Range: YS0201-YS0366 |
| 113. | ZH42X04000 | [1] | 45 ELBOW,Male, 30 Degree Fl, PF 1/4" x PF 1/4", O-Ring | KOBElbow, 45° -- (Incls. O-Ring 237-6004) |
| 114. | 2420R349D160 | [1] | HOSE,6.35mm ID x 1600mm L | KOB |
| 115. | 2436U1171D21 | [1] | CHECK VALVE | KOB |
| 116. | ZX15K08330 | [1] | TUBE | KOB |
| 117. | 2444T2524 | [3] | HYD CONNECTOR | KOB1/4" PF x 50mm Long (Incls. O-Ring ZD12P01100), Serial Range: YS0201-YS0253 |
| . . | 2444T2524 | [2] | HYD CONNECTOR | KOB1/4" PF x 50mm Long (Incls. O-Ring ZD12P01100), Start Serial: YS0254 |
| 118. | 2444T3298 | [1] | TEE | KOB3/8" PF - 1/4" PF (Incls. O-Ring ZD12P01100) |
| 119. | ZW11K06000 | [8] | WASHER | KOBID 06 x OD 11.5 x Th 1.6mm |
| 120. | 2436U1354F1 | [2] | PILOT VALVE | KOB |
| 121. | ZS18C10030 | [4] | SCREW,Hex, M10 x 30mm | KOBM10x1.50x30mm |
| 122. | ZW26X10000 | [4] | LOCK WASHER | KOBID 10 x OD 18 x Th 2.5mm |
| 124. | ZS23C06030 | [8] | SCREW,Hex Socket Head, M6 x 30mm | KOBM06x1.0x30mm |
| 132. | 2444Z3410 | [1] | HYD CONNECTOR | KOB |
| 133. | 2444Z2448F4 | [1] | CONNECTOR ASSY (WITH FILTER) | |
| 134. | 2444Z3783 | [2] | 90 ELBOW | KOB90° -- 1/4" PT (Incls. O-Ring ZD12P01100), Start Serial: YS0402 |
| 135. | 2444Z3785 | [1] | HYD CONNECTOR | KOB1/4" PT (Incls. O-Ring ZD12P01100), Start Serial: YS0402 |
| 136. | 2444Z2477F4 | [1] | HYD CONNECTOR | KOB(WITH FILTER) |
| 137. | 2444Z2477F5 | [1] | HYD CONNECTOR | KOB(WITH FILTER) |
| 138. | 2414U167 | [2] | BOOT | KOB |
| 139. | 2444R974D2 | [1] | HOSE | KOB |
| 140. | 2436U1287F1 | [2] | PILOT VALVE | KOB, Serial Range: YS0201-YS0366 Superseded by part number: 2436U1287F3 |
| . . | 2436U1287F3 | [2] | PILOT VALVE | KOB, Start Serial: YS0367 |
| 141. | 2444T2592 | [2] | TEE | KOB3/8" PF - 1/4" PF (No O-Ring supplied) |
| 142. | 2479Z1099 | [2] | SWITCH | KOB Superseded by part number: 2479Z1099M |
| 143. | 2420T3483 | [4] | GROMMET | KOB |
| 144. | 2444Z2516 | [1] | HYD CONNECTOR | KOB(Incls. O-Ring ZD12P01100), Start Serial: YS0254 |
| 145. | 2444Z2526 | [1] | TEE | KOB |
| 146. | 2425Z519 | [2] | BALL | KOB |
| 147. | 2444Z2446 | [1] | ELBOW | KOB, Serial Range: YS0201-YS0207 |
| 149. | ZW16X08000 | [1] | WASHER,8mm ID x 17mm OD x 1.6mm Thk | KOBID 08 x OD 17 x Th 1.6mm |
| 150. | 2444T2558 | [1] | HYD CONNECTOR | KOB |
| 151. | 2444T3202 | [1] | HYD CONNECTOR | KOB |
| 152. | ZW22X06000 | [1] | LOCK WASHER ID 06 x OD 12.2 x Th 1.5mm | LOCK WASHER ID 06 x OD 12.2 x Th 1.5mm |
| 153. | 2444Z3333 | [1] | CONNECTOR | |
| 154. | ZW22K06000 | [8] | LOCK WASHER | KOBID 06 x OD 10 x Th 1.5mm |
| 155. | 2444T2529 | [1] | TEE | KOB1/4" PF x 50mm Long (Incls. O-Ring ZD12P01100) |
| 156. | 2444T2533 | [1] | TEE | KOB(Incls. O-Ring ZD12P01400) Superseded by part number: 87635046 |
| 158. | ZN18C14011 | [2] | NUT | KOBM14x2.0mm |
| 159. | 2416P13806 | [1] | BRACKET | KOB |
| 160. | ZS13C10020 | [2] | SCREW | KOBM10x1.50x20mm Superseded by part number: ZS18C10020 |
| 161. | ZS13C06050 | [1] | CAPSCREW | |
| 162. | 2420R537D305 | [2] | FLEXIBLE HOSE,9.60mm ID x 3050mm L | KOB Superseded by part number: HX21E06305DX |
| 163. | 2420R537D325 | [2] | FLEXIBLE HOSE,9.60mm ID x 3250mm L | KOB |
| 164. | 2420R537D350 | [1] | HOSE ASSY.,9.60mm ID x 3500mm L | KOB3500mm Long (137-51/64 in) Superseded by part number: HX21E06350DX |
| 165. | 2420R537D345 | [1] | FLEXIBLE HOSE,9.60mm ID x 3450mm L | KOB |
| 166. | 2420R537D340 | [3] | HOSE ASSY.,9.60mm ID x 3400mm L | KOB |
| 168. | 2420R537D290 | [1] | HOSE,9.53mm ID x 2900mm L | KOB |
| 169. | 2420R537D260 | [1] | HOSE,9.60mm ID x 2600mm L | KOB |
| 171. | 2420R537D320 | [1] | HOSE ASSY.,9.60mm ID x 3200mm L | KOB3200mm Long (126 in) |
| 172. | 2444Z4080 | [4] | HYD CONNECTOR | KOB, Start Serial: YS0402 |
| 173. | 2444Z2544 | [1] | TEE | KOB1/4"PTx60mm Long (No O-Ring supplied), Start Serial: YS0402 |
