| . . | 24100N5680F3 | [1] | REWORK, CONTROL ASSY | |
| 1. | 2436U1314F1 | [1] | VALVE | KOB |
| 2. | 2436R732F1 | [1] | SOLENOID VALVE | KOB |
| 3. | 2479R1337F1 | [1] | PRESSURE SWITCH | KOB |
| 4. | 2436R757F2 | [1] | VALVE | KOB |
| 5. | 2416P13539 | [1] | BRACKET | KOB |
| 7. | 2479Z1096 | [1] | SWITCH | KOB |
| 8. | 2479R1419 | [1] | WIRE HARNESS | KOB |
| 10. | 2479U717S6 | [1] | FUSE,10 Amp | KOB10 Amp |
| 11. | 2412T935 | [1] | LABEL | KOB |
| 12. | 2432P1085 | [1] | LABEL | KOB |
| 14. | ZS13C05050 | [2] | BOLT | BOLT |
| 15. | ZN13C06005 | [4] | NUT | KOBM06x1.0mm Superseded by part number: ZN18C06005 |
| 16. | ZF23G10004 | [1] | HYD CONNECTOR | KOB |
| 17. | 2444Z2538 | [1] | HYD CONNECTOR | KOB |
| 18. | 2412T980 | [1] | STICKER | STICKER |
| 20. | ZW22K06000 | [6] | LOCK WASHER | KOBID 06 x OD 10 x Th 1.5mm |
| 21. | ZS13C10020 | [2] | SCREW | KOBM10x1.50x20mm Superseded by part number: ZS18C10020 |
| 22. | ZW22X10000 | [2] | LOCK WASHER | KOBID 10 x OD 18.4 x Th 2.5mm Superseded by part number: ZW26X10000 |
| 23. | 2444Z2539 | [1] | HYD CONNECTOR | KOB |
| 24. | ZW26X05000 | [2] | LOCK WASHER | KOBLock -- ID 05 x OD 09 x Th 1.3mm |
| 25. | ZS23C06016 | [2] | SCREW,Hex Socket Head, M6 x 16mm | KOBM06x1.0x16mm Superseded by part number: ZS28C06016 |
| 29. | ZX56N04140 | [1] | HOSE | KOB |
| 30. | ZX56N04060 | [1] | HOSE | HOSE |
| 32. | ZH32X04000 | [3] | 90 ELBOW,Male, 30 Degree Fl, PF 1/4" x PF 1/4", O-Ring | KOBElbow, 90° -- PF 1/4, (Incls. O-Ring 237-6004) |
| 33. | ZH22X04000 | [1] | HYD CONNECTOR,1/4" NPT x 1/4" NPT | KOB1/4"PFx36mm Long (Incls. O-Ring ZD12P01100) |
| 34. | ZH31M08004 | [2] | ELBOW | KOB |
| 35. | ZH51K08000 | [2] | TEE | KOB |
| 36. | 2444R963D11 | [1] | FLEXIBLE HOSE | KOB550 mm long (21-21/32 in) Superseded by part number: HX31E04055DX |
| 37. | 2444R963D20 | [2] | FLEXIBLE HOSE | KOB350 mm long (13-49/64 in) Superseded by part number: 77258641, HX31E04035DX |
| 38. | 2420R537D140 | [1] | HOSE ASSY.,9.60mm ID x 1400mm L | KOB1400mm Long (55-7/64 in) |
| 39. | 2444Z2336 | [3] | TEE | KOBTee -- 1/4"x3/8"x3/8"PF (Incls. O-Ring ZD12P01100) |
| 40. | ZX15K08100 | [3] | TUBE | KOB |
| 41. | 2420R349D050 | [1] | HOSE,500.00 mm | KOB500mm Long (19-11/16 in) |
| 42. | 2420R349D140 | [1] | HOSE,6.35mm ID x 1400mm L | KOB1/4" PF |
| 43. | 2420R537D190 | [1] | FLEXIBLE HOSE,9.60mm ID x 1900mm L | KOB1900mm Long (74-13/16 in) Superseded by part number: HX21E06190DX |
| 44. | 2444Z2335 | [4] | CONNECTION | KOB |
| 45. | ZH22X06000 | [4] | HYD CONNECTOR | KOB(Incls. O-Ring ZD12P01400) |
| 46. | ZS23C06020 | [4] | SCREW,Hex Socket Head, M6 x 20mm | KOBM06x1.0x20mm Superseded by part number: ZS28C06020 |
| 47. | 2432N2142 | [1] | LABEL | LABEL |
| 48. | ZH52X06000 | [1] | TEE,30 Degree Fl, Male, PF 3/8" x 3/8" x 3/8", O-Ring | KOB3/8"PFx54mm Long (Incls. O-Ring ZD12P01400) |
