神钢零件查询(MD450BLC) - EXCAVATOR BTW TS0201 - TS0394 (1/80-12/06) (05-004) - PUMP ASSY, CONNECT Kobelco
广数供应链运营团队, 15 02月, 2025，浏览：
644 次
| Pos. | Part No | Qty | Parts name | Comments |
|---|
| . . | 24100N5599F1 | [1] | PUMP ASSY, CONNECT YS0201, LS0201 to YS0279, LS0267 | |
| . . | 24100N5599F2 | [1] | PUMP ASSY, CONNECT YS0280, Start Serial: LS0268 | |
| 2. | 2441U291F2 | [1] | HYDRAULIC PUMP | KOB |
| 1. | 2441U774F1 | [1] | PUMP | KOBYS0201, LS0201 to YS0279, LS0267 Superseded by part number: 2441U774F3 |
| 3. | 2416N5181 | [1] | U-BRACKET | KOB |
| 4. | ZS23C10035 | [12] | SCREW,Hex Socket Head, M10 x 35mm | KOBM10x1.50x35mm |
| 5. | ZS23C20060 | [4] | SCREW,Hex Socket Head, M20 x 60mm | KOBM20x2.5x60mm |
| 6. | ZD12G05500 | [1] | O-RING,3.1mm Thk x 54.4mm ID, 90 Duro | KOBO -- ID 54.40 ± 0.49 x OD 60mm |
| 7. | ZS13C10025 | [2] | CAPSCREW | KOBSCREW M10x1.50x25mm Superseded by part number: ZS18C10025 |
| 8. | ZW11K10000 | [2] | WASHER | KOBID 10 x OD 18 x Th 2.0mm |
| 9. | 2441U774F2 | [1] | PUMP | KOBPUMP ASSY YS0280, LS0260 to YS0315, LS0321 Superseded by part number: 2441U774F3 |
| . . | 2441U774F3 | [1] | PUMP | KOBYS0316, Start Serial: LS0322 |
