现代零件查询R800LC-7A BOOM SAFETY LOCK SYSTEMEPC Hyundai
广数供应链运营团队, 15 02月, 2025，浏览：
916 次
| Pos. |
Part No |
Qty |
Parts name |
Comments |
| 1. |
31ND-53010
|
[1] |
BOOM SAFTY LOCK CYL-LH
|
|
| 1. |
31ND-53011
|
[1] |
BOOM SAFTY LOCK CYL-LH
|
|
| 1-0. |
@
|
[1] |
BOOM CYL SUB ASSY
|
|
| 1-1. |
31ND-55011
|
[1] |
SAFETY LOCK VALVE
|
|
| 1-1-1. |
XKCH-00001
|
[1] |
RELIEF VALVE
|
|
| 1-1-2. |
XKCH-00003
|
[1] |
SEAL KIT
|
|
| 1-2. |
XKCD-00581
|
[1] |
PIPE ASSY-LH
|
|
| 1-2. |
XKCD-01566
|
[1] |
PIPE ASSY-LH
|
|
| 1-3. |
XKCD-00499
|
[1] |
O-RING
|
|
| 1-4. |
XKCD-00583
|
[4] |
BOLT-HEX SOCKET
|
|
| 1-5. |
XKCD-00501
|
[8] |
WASHER-SPRING
|
|
| 1-6. |
XKCD-00586
|
[4] |
BOLT-HEX SOCKET
|
|
| 2. |
31ND-53020
|
[1] |
BOOM SAFTY LOCK CYL-RH
|
|
| 2. |
31ND-53021
|
[1] |
BOOM SAFTY LOCK CYL-RH
|
|
| 2-0. |
@
|
[1] |
BOOM CYL SUB ASSY
|
|
| 2-1. |
31ND-55011
|
[1] |
SAFETY LOCK VALVE
|
|
| 2-1-1. |
XKCH-00001
|
[1] |
RELIEF VALVE
|
|
| 2-1-2. |
XKCH-00003
|
[1] |
SEAL KIT
|
|
| 2-2. |
XKCD-00588
|
[1] |
PIPE ASSY-RH
|
|
| 2-2. |
XKCD-01567
|
[1] |
PIPE ASSY-RH
|
|
| 2-3. |
XKCD-00499
|
[1] |
O-RING
|
|
| 2-4. |
XKCD-00583
|
[4] |
BOLT-HEX SOCKET
|
|
| 2-5. |
XKCD-00501
|
[8] |
WASHER-SPRING
|
|
| 2-6. |
XKCD-00586
|
[4] |
BOLT-HEX SOCKET
|
|
| 3. |
P933-047018
|
[3] |
HOSE ASSY-ORFS 0X90
|
|
| 4. |
P913-047030
|
[1] |
HOSE ASSY-ORFS 0X0
|
|
| 5. |
P930-062071
|
[1] |
HOSE ASSY-ORFS 0X90
|
|
| 6. |
P930-062097
|
[1] |
HOSE ASSY-ORFS 0X90
|
|
| 7. |
31E5-50325
|
[1] |
SWITCH-PRESSURE
|
|
| 7-1. |
31E5-50320
|
[1] |
SWITCH-PRESSURE
|
|
| 7-2. |
21E5-50230
|
[1] |
HARNESS-EXT
|
|
| 8. |
31E6-90551
|
[1] |
BLOCK
|
|
| 9. |
XKAY-00817
|
[4] |
CONNECTOR
|
|
| 10. |
X820-085252
|
[1] |
TEE-R/TYPE,ORFS
|
|
| 11. |
X820-045151
|
[1] |
TEE-R/TYPE,ORFS
|
|
| 12. |
X840-525252
|
[1] |
TEE-R/TYPE,SWIVEL,ORFS
|
|
| 13. |
31N9-90550
|
[2] |
TEE-R/TYPE,ORFS
|
|
| 14. |
S411-050006
|
[2] |
WASHER-SPRING
|
|
| 15. |
S411-120006
|
[2] |
WASHER-SPRING
|
|
| 16. |
S015-050456
|
[2] |
BOLT-HEX
|
|
| 17. |
S017-120556
|
[2] |
BOLT-HEX
|
|
