神钢零件查询(MD450BLC) - EXCAVATOR BTW TS0201 - TS0394 (1/80-12/06) (05-013) - BATTERY ASSY Kobelco
广数供应链运营团队, 15 02月, 2025，浏览：
962 次
| Pos. | Part No | Qty | Parts name | Comments |
|---|
| . . | 24100P2648P1 | [1] | BATTERY ASSY | |
| 1. | 2484U177 | [2] | BATTERY F160-12 YS0201, LS0201 to YS0212, LS0212 | |
| . . | 2484U178 | [2] | BATTERY FH13 OF 51 YS0213, Start Serial: LS0213 | |
| 4. | 2418P5535 | [1] | PLATE | KOB |
| 5. | R20T084D20 | [2] | CAPSCREW YS0201, LS0201 to YS0263, LS0242 | |
| 6. | 2418T5373C2 | [2] | WASHER | KOBID 11 x OD 30 x Th 3.20mm Superseded by part number: 2418T12346 |
| 7. | ZW26X10000 | [2] | LOCK WASHER | KOBID 10 x OD 18 x Th 2.5mm |
| 8. | 2418T29527 | [2] | SPACER YS0201, LS0201 to YS0263, LS0242 | |
| 9. | R20T0084D17 | [2] | CAPSCREW | KOBSCREW M10x1.50x235mm YS0264, Start Serial: LS0243 |
| . . | 24100P2648F2 | [1] | BATTERY ASSY | |
| 2. | 2484U176 | [2] | BATTERY 15 OF 51 | |
| 5. | R20T0084D20 | [2] | SCREW | KOBM10x1.50x255mm YS0201, LS0201 to YS0263, LS0242 |
| 8. | 2418T19527 | [2] | SPACER | KOBYS0201, LS0201 to YS0263, LS0242 |
| . . | 24100P2648F3 | [1] | BATTERY ASSY | |
| 3. | 2484U175 | [2] | BATTERY 17 OF 51 | BATTERY 17 OF 51 |
