现代零件查询R800LC-7A CENTRAL GREASE LUB SYS 3(2.95M, #0106-)EPC Hyundai _现代Hyundai_工程机械

现代零件查询R800LC-7A CENTRAL GREASE LUB SYS 3(2.95M, #0106-)EPC Hyundai

广数供应链运营团队, 15 02月, 2025，浏览： 262 次

Pos.	Part No	Qty	Parts name	Comments
.	@	[1]	KIT-AUTO GREASE PIPING	SEE 3601
-3.	31QD-82300	[1]	ARM PIPING	2.95M ARM
-3.	31QD-82301	[1]	ARM PIPING	2.95M ARM
-3.	31QD-81300	[1]	ARM PIPING	3.4M ARM
-3.	31QD-81301	[1]	ARM PIPING	3.4M ARM
-3.	31QD-84300	[1]	ARM PIPING	3.6M ARM
-3.	31QD-84301	[1]	ARM PIPING	3.6M ARM
1.	31QD-82560	[1]	DISTRIBUTOR-D3	2.95M ARM
1.	31QD-81560	[1]	DISTRIBUTOR-D3	3.4M ARM
1.	31QD-84560	[1]	DISTRIBUTOR-D3	3.6M ARM
1-1.	XKCE-00060	[1]	ELEMENT-TOP
1-2.	XKCE-00057	[1]	BRIDGE
1-3.	XKCE-00039	[1]	ELEMENT-MIDDLE
1-4.	XKCE-00040	[1]	ELEMENT-MIDDLE
1-5.	XKCE-00041	[1]	ELEMENT-MIDDLE
1-6.	XKCE-00044	[1]	ELEMENT-END
1-7.	XKCE-00049	[2]	BOLT
1-8.	XKCE-00034	[2]	WASHER-SPRING
1-9.	XKCE-00193	[1]	INSERT-FERRULE
1-10.	XKCE-00194	[11]	INSERT-FERRULE
1-11.	XKCE-00187	[12]	FERRULE-THEADED
1-12.	XKCE-00051	[6]	VALVE-CHECK
1-13.	XKCE-00052	[10]	BOLT-BLANK
1-14.	XKCE-00198	[1]	FILLER NIPPLE-RETURN
1-15.	XKCE-00224	[1]	HOSE-H/PRESSURE	2.95M ARM
1-15.	XKCE-00309	[1]	HOSE-H/PRESSURE	3.4M ARM
1-15.	XKCE-00331	[1]	HOSE-H/PRESSURE	3.6M ARM
1-16.	XKCE-00225	[1]	HOSE-H/PRESSURE	2.95M ARM
1-16.	XKCE-00310	[1]	HOSE-H/PRESSURE	3.4M ARM
1-16.	XKCE-00332	[1]	HOSE-H/PRESSURE	3.6M ARM
1-17.	XKCE-00226	[1]	HOSE-H/PRESSURE	2.95M ARM
1-17.	XKCE-00311	[1]	HOSE-H/PRESSURE	3.4M ARM
1-17.	XKCE-00333	[1]	HOSE-H/PRESSURE	3.6M ARM
1-18.	XKCE-00227	[1]	HOSE-H/PRESSURE	2.95M ARM
1-18.	XKCE-00312	[1]	HOSE-H/PRESSURE	3.4M ARM
1-18.	XKCE-00334	[1]	HOSE-H/PRESSURE	3.6M ARM
1-19.	XKCE-00228	[1]	HOSE-H/PRESSURE	2.95M ARM
1-19.	XKCE-00313	[1]	HOSE-H/PRESSURE	3.4M ARM
1-19.	XKCE-00335	[1]	HOSE-H/PRESSURE	3.6M ARM
1-20.	XKCE-00229	[1]	HOSE-H/PRESSURE	2.95M ARM
1-20.	XKCE-00314	[1]	HOSE-H/PRESSURE	3.4M ARM
1-20.	XKCE-00336	[1]	HOSE-H/PRESSURE	3.6M ARM
1-21.	XKCE-00057	[1]	BRIDGE
2.	XKCE-00054	[3]	BOLT
3.	XKCE-00055	[7]	WASHER-SPRING
4.	XKCE-00184	[7]	FITTING-STRIGHT
5.	XKCE-00199	[2]	ELBOW-FITTING
6.	XKCE-00045	[17]	BOLT
7.	XKCE-00033	[17]	WASHER-SPRING
8.	XKCE-00180	[5]	CLAMP-HOSE
9.	XKCE-00181	[9]	CLAMP-HOSE
10.	XKCE-00182	[2]	CLAMP-HOSE
11.	XKCE-00196	[4]	NIPPLE-GREASE
12.	XKCE-00243	[1]	PIPE	2.95M ARM
12.	XKCE-00415	[1]	HOSE-H/PRESSURE	3.4M ARM
12.	XKCE-00409	[1]	HOSE-H/PRESSURE	3.6M ARM
13.	XKCE-00400	[1]	SPRING	2.95M ARM
13.	XKCE-00416	[1]	SPRING	3.4M ARM
13.	XKCE-00410	[1]	SPRING	3.6M ARM
14.	XKCE-00244	[1]	PIPE	2.95M ARM
14.	XKCE-00417	[1]	HOSE-H/PRESSURE	3.4M ARM
14.	XKCE-00411	[1]	HOSE-H/PRESSURE	3.6M ARM
15.	XKCE-00401	[1]	SPRING	2.95M ARM
15.	XKCE-00418	[1]	SPRING	3.4M ARM
15.	XKCE-00412	[1]	SPRING	3.6M ARM
16.	XKCE-00245	[1]	PIPE	2.95M ARM
16.	XKCE-00419	[1]	HOSE-H/PRESSURE	3.4M ARM
16.	XKCE-00413	[1]	HOSE-H/PRESSURE	3.6M ARM
17.	XKCE-00402	[1]	SPRING	2.95M ARM
17.	XKCE-00420	[1]	SPRING	3.4M ARM
17.	XKCE-00414	[1]	SPRING	3.6M ARM
18.	XKCE-00239	[1]	HOSE-H/PRESSURE	2.95M ARM
18.	XKCE-00307	[1]	HOSE-H/PRESSURE	3.4M ARM
18.	XKCE-00329	[1]	HOSE-H/PRESSURE	3.6M ARM
19.	XKCE-00240	[1]	SPRING	2.95M ARM
19.	XKCE-00308	[1]	SPRING	3.4M ARM
19.	XKCE-00330	[1]	SPRING	3.6M ARM
20.	XKCE-00051	[3]	VALVE-CHECK
21.	XKCE-00204	[2]	INSERT-FERRULE
22.	XKCE-00205	[2]	FERRULE-THEADED
23.	XKCE-00184	[1]	FITTING-STRIGHT
24.	XKCE-00206	[1]	VALVE-CHECK
-4.	31QD-81400	[1]	CONTROL ROD PIPING
51.	31QD-81550	[1]	DISTRIBUTOR-D2
51-1.	XKCE-00060	[1]	ELEMENT-TOP
51-2.	XKCE-00039	[2]	ELEMENT-MIDDLE
51-3.	XKCE-00044	[1]	ELEMENT-END
51-4.	XKCE-00046	[2]	BOLT
51-5.	XKCE-00034	[2]	WASHER-SPRING
51-6.	XKCE-00193	[7]	INSERT-FERRULE
51-7.	XKCE-00189	[1]	INSERT-FERRULE
51-8.	XKCE-00187	[8]	FERRULE-THEADED
51-9.	XKCE-00051	[4]	VALVE-CHECK
51-10.	XKCE-00052	[6]	BOLT-BLANK
51-11.	XKCE-00184	[1]	FITTING-STRIGHT
51-12.	XKCE-00216	[1]	HOSE-H/PRESSURE
51-13.	XKCE-00217	[1]	HOSE-H/PRESSURE
51-14.	XKCE-00218	[1]	HOSE-H/PRESSURE
51-15.	XKCE-00219	[1]	HOSE-H/PRESSURE
51-16.	XKCE-00220	[1]	SPRING
51-17.	XKCE-00221	[1]	SPRING
51-18.	XKCE-00222	[1]	SPRING
51-19.	XKCE-00223	[1]	SPRING
51-20.	XKCE-00057	[1]	BRIDGE
52.	XKCE-00054	[3]	BOLT
53.	XKCE-00055	[3]	WASHER-SPRING
54.	XKCE-00184	[2]	FITTING-STRIGHT
55.	XKCE-00199	[2]	ELBOW-FITTING
56.	XKCE-00065	[4]	BOLT
57.	XKCE-00056	[4]	WASHER-SPRING
58.	XKCE-00242	[1]	DISTRIBUTOR COVER-D2
59.	XKCE-00184	[1]	FITTING-STRIGHT
60.	XKCE-00249	[1]	INSET-FERRULE
