凯斯零件查询(4300) - TITAN FLOATER (6/98-8/99) (02-005) - THROTTLE CABLE ASSEMBLY 4330 ONLY Case Agriculture
广数供应链运营团队, 15 02月, 2025，浏览：
673 次
| Pos. |
Part No |
Qty |
Parts name |
Comments |
| 1. |
BN2396298
|
[1] |
BALL
|
BN
Throttle
|
| 2. |
BN2296346
|
[1] |
CLAMP
|
BN
Cable
|
| 3. |
BN7136345
|
[1] |
SHEET
|
BN
Throttle Cable Bracet
|
| 4. |
BN1913307F
|
[1] |
HH 1/4-28 X 3/4 NF
|
|
| 5. |
BN1470052
|
[2] |
NUT
|
BN
NF 1/4-28 Superseded by part number: 86509309
|
| 6. |
BN2292245
|
[1] |
HYDRAULIC VALVE
|
BN
|
| 7. |
BN2296345
|
[1] |
CLEVIS
|
BN
|
| 8. |
BN305707
|
[1] |
BRACKET
|
TYR
Throttle (CAT 3208T)
|
| 11. |
BN1470402C
|
[1] |
FLANGE NUT
|
BN
1/4-20, FLN, G8 Superseded by part number: 280129
|
| 12. |
BN1913317C
|
[2] |
BOLT
|
BN
HH 1/4-20 X 1 NC G5 Superseded by part number: 413-416
|
| 14. |
BN2297820
|
[1] |
ROD
|
BN
End
|
| 15. |
BN306908
|
[1] |
ROD
|
BN
Adjustment
|
| 16. |
BN2290506
|
[1] |
FITTING
|
BN
2103-4-4
|
| 18. |
BN2303140
|
[4] |
PLATE
|
BN
Flat 1/4 Superseded by part number: 80701
|
| 19. |
BN1470002
|
[2] |
NUT
|
BN
1/4-20, HH, G5 Superseded by part number: 280129
|
| 20. |
80682
|
[2] |
LOCK WASHER,1/4"
|
PA
|
| 21. |
BN7143182
|
[1] |
BAR
|
BN
Spacer - Throttle
|
