神钢零件查询(200-8) - EXCAVATOR S/N YN11-45001 - (1/06-12/09) (020-01-1) - ENGINE ASSY Kobelco
广数供应链运营团队, 15 02月, 2025，浏览：
389 次
| Pos. | Part No | Qty | Parts name | Comments |
|---|
| . . | YN02P00034F1 | [1] | Instal | |
| . . | YN02P00031F1 | [1] | Instal (See Fig No.025-01-1,2) | |
| 1. | YN02P00028F1 | [1] | ENGINE | KOBAssy, Serial Range: YQ11-06001-YQ11-06076 |
| 1-1. | YN22E00263F1 | [1] | CONTROLLER | KOBAssy |
| . . | YN02P00042F1 | [1] | ENGINE | KOBAssy, Serial Range: YQ11-06077-YN11-46018 Superseded by part number: YN02P00083F2 |
| 2. | YN05P01479P1 | [1] | HOSE | KOBRadiator |
| 3. | YN05P01494P1 | [1] | RADIATOR HOSE | KOB |
| 4. | YN05P01439P1 | [1] | HOSE | KOB |
| 5. | YN05P01495P1 | [1] | HOSE | KOB |
| 6. | YN20M01494D1 | [1] | BELT | KOBV (conditioner, Air) (COG B66) |
| 1-1A. | YN22E00263S001 | [1] | CONTROLLER | KOBUnprogrammed - Hino pn VH89661E0010 Superseded by part number: VH89661E0010 |
| 1-1B. | YN22E00263S002 | [1] | Software Not serviced | |
| 7. | VH900149375A | [1] | SET OF 2 BELTS | KOBV-belt (2 Pieces Set) (2) Superseded by part number: VHSZ91049200 |
| 8. | VH281002894A | [1] | STARTER MOTOR,24V, 5KW | KOBAssy Superseded by part number: VH28100E0080 |
| 9. | VH270402192A | [1] | ALTERNATOR | KOBAssy Superseded by part number: VHS270402192 |
| 10. | VH040166104A | [1] | THERMOSTAT | KOBKit Superseded by part number: VHS1632E9040 |
| 11. | VH156601090A | [1] | PLUG | KOBAssy, Oil Superseded by part number: VHS156601090 |
| 12. | YN30T01001P1 | [1] | ELEMENT | KOBFilter Oil E/G Hino pn VH156072190A Superseded by part number: VHS156072190 |
| 13. | YN30T01002P1 | [1] | ELEMENT | KOBFilter Fuel E/G Hino pn VH23390E0010 Superseded by part number: VH23390E0011 |
| 14. | VH834601510A | [1] | SWITCH | KOBAssy, Level Warning Superseded by part number: VHS834601510 |
| 15. | VH985119116A | [1] | O-RING | KOB Superseded by part number: VHSZ30119013 |
| 16. | VH894101290A | [1] | SENSOR | KOBAssy Superseded by part number: VHS894101290 |
