凯斯零件查询(4330) - TITAN FLOATER (6/98-8/99) (04-007) - REAR AXLE CARRIER Case Agriculture
广数供应链运营团队, 15 02月, 2025，浏览：
977 次
| Pos. |
Part No |
Qty |
Parts name |
Comments |
| 1. |
BN2390129-009
|
[1] |
NUT
|
BN
Pinion New #2636
|
| 2. |
BN2292588
|
[1] |
YOKE
|
BN
End 6-4-5131X (1710)
|
| 3. |
BN2390129-001
|
[1] |
SEAL
|
BN
Pinion, #415082N
|
| 4. |
BN2390129-042
|
[1] |
BOLT
|
BN
Cage Assembly, Pinion Bearing
|
| 5. |
BN2390129-041
|
[1] |
BEARING ASSY
|
BN
Cage, Pinion
|
| 6. |
BN2390129-002
|
[1] |
BOOT
|
BN
Shifter
|
| 7. |
BN2390129-016
|
[1] |
RING GEAR
|
BN
Pinion Assembly
|
| 7A. |
BN2390129-022
|
[1] |
CARRIER
|
BN
Assembly, 4.88/6.80 Low Speed (Standard)
|
| 7B. |
BN2390129-007
|
[1] |
CARRIER
|
BN
Assembly, Rear Axle, 3.91-5.45
|
