凯斯零件查询(4330) - TITAN FLOATER (6/98-8/99) (07-001) - PNEUMATIC ASSEMBLY Case Agriculture
广数供应链运营团队, 15 02月, 2025，浏览：
692 次
| Pos. |
Part No |
Qty |
Parts name |
Comments |
| 2. |
BN7135009-A
|
[1] |
Hand Throttle Valve Assembly
|
|
| 3. |
BN7148131
|
[1] |
BRAKE VALVE
|
BN
Pedal Assembly
|
| 4. |
BN7148013-A
|
[1] |
BRAKE VALVE
|
BN
Parking Assembly
|
| 5. |
BN7148001-A
|
[1] |
HYDRAULIC VALVE
|
BN
Quick Release Assembly-Front Brake
|
| 6. |
BN7138035
|
[1] |
HYDRAULIC VALVE
|
BN
Quick Release Assembly-Park Brake
|
| 7. |
BN7138034
|
[1] |
HYDRAULIC VALVE
|
BN
Quick Release Assembly-Rear Brake Superseded by part number: 87342645, 87343959, BN2298276, BN2290508, BN2290528, BN2390660
|
| 8. |
BN7148104
|
[1] |
Secondary Air Tank
|
|
| 9. |
BN7148103
|
[1] |
Primary Air Tank 4W
|
|
| 10. |
BN7148162
|
[1] |
Assembly, 2-Speed Shift CIRC
|
|
| 11. |
BN7148114-B
|
[1] |
Assembly, Air
|
|
| 12. |
BN7148023
|
[1] |
RECEIVER-DRYER
|
BN
Assembly, Air (Spin-On)
|
| 13. |
BN2290728
|
[1] |
GAUGE
|
BN
Air Pressure (10-150) 8
|
| 14. |
BN3600021-114.25
|
[1] |
Assembly 919-10-01
|
|
| 15. |
BN3600001-114.38
|
[1] |
Assembly 451 AR-4-01
|
|
| 16. |
BN3600003-066.70
|
[1] |
Assembly 451 AR-8-01
|
|
| 17. |
BN3600002-022.54
|
[1] |
Assembly 451 AR-6-01
|
|
| 18. |
BN3600002-036.54
|
[1] |
Assembly 451 AR-6-01
|
|
| 19. |
BN3600002-034.54
|
[1] |
Assembly 451 AR-6-01
|
|
| 21. |
BN3600001-162.38
|
[1] |
Assembly 451 AR-4-01
|
|
| 22. |
BN3600002-032.54
|
[1] |
Assembly 451 AR-6-01
|
|
| 23. |
BN3600002-018.54
|
[1] |
Assembly 451 AR-6-01
|
|
| 24. |
BN68493
|
[1] |
HOSE
|
BN
1/4" x 170"
|
| 25. |
BN3600003-180.70
|
[1] |
Assembly 451 AR-8-01
|
|
| 26. |
BN3600003-076.70
|
[1] |
Assembly 451 AR-8-01
|
|
| 27. |
BN3600003-056.70
|
[1] |
Assembly 451 AR-8-01
|
|
| 28. |
BN3600001-034.38
|
[1] |
Assembly 451 AR-4-01
|
|
| 29. |
BN3600001-056.38
|
[1] |
Assembly 451 AR-4-01
|
|
| 30. |
BN3600003-044.70
|
[1] |
Assembly 451 AR-8-01
|
|
| 31. |
NSS
|
[1] |
NOT SOLD SEPARAT
|
CON
Tubing, SYN 1/4 Black
|
| 32. |
BN2292088
|
[1] |
AIR INTAKE TUBE
|
BN
3/8" Black Superseded by part number: 84422568
|
| 34. |
BN2393053
|
[1] |
TUBE,1/4" X 100' BULK, SAE J844, GREEN
|
BN
Air, Synflex 1/4" Green
|
| 35. |
BN3600001-112.38
|
[1] |
Assembly 451 AR-4-01
|
|
| 36. |
BN305697
|
[1] |
CYLINDER
|
BN
Air Throttle Cylinder
|
