神钢零件查询(200-8) - EXCAVATOR S/N YN11-45001 - (1/06-12/09) (160-01-1) - CONTROL LINES, PROPEL Kobelco
广数供应链运营团队, 15 02月, 2025，浏览：
719 次
| Pos. | Part No | Qty | Parts name | Comments |
|---|
| . . | YN62H00026F1 | [1] | Control, Propel | |
| A1. | YN30V00105F1 | [1] | VALVE | KOBAssy, Pilot Superseded by part number: YN30V00105F2 |
| A2. | 2420R349D085 | [2] | HOSE,6.35mm ID x 850mm L | KOB |
| A3. | 2420R349D155 | [2] | HOSE,6.35mm ID x 1150mm L | KOB |
| A4. | 2420R349D345 | [1] | HOSE | KOB |
| A5. | 2420R349D360 | [1] | HOSE,3600.00 mm | KOB Superseded by part number: HX21E04360DX |
| A6. | HH25X04004G2 | [1] | HYD CONNECTOR | KOB |
| A7. | ZH22X04006 | [1] | HYD CONNECTOR | KOB |
| A8. | ZH32X04006 | [4] | 90 ELBOW,Male, 30 Degree Fl, PF 1/4" x PF 3/8", O-Ring | KOB |
| A9. | YX52S00013P1 | [2] | SENSOR | SMPress (L.P), Serial Range: YQ11-06001-YQ11-06105 Superseded by part number: LC52S00019P1 |
| . . | LC52S00019P1 | [2] | SENSOR | SMPress (L.P) Incls. O-Ring ZD12P01100, Start Serial: YQ11-06106 |
| A9-2. | ZD12P01100 | [1] | O-RING | KOBID 10.8mm x OD 13.2mm |
| A10. | YN62H01015P1 | [4] | RUBBER BAND | KOB |
| A11. | HM83C10030G1 | [4] | BOLT | KOBSems |
| A12. | YN13E01375P1 | [1] | CLIP,M8 x 8.20mm Shank | KOB |
| A13. | PY01P01043D8 | [1] | CABLE TIE,102mm L | KOB |
| . . | YN64H00185F1 | [1] | Control, Block | |
| B1. | YN64H01291P1 | [1] | BLOCK | KOB |
| B2. | 2420R349D110 | [1] | HOSE,1100.00 mm | KOB Superseded by part number: HX21E04110DX |
| B3. | 2420R349D120 | [1] | HOSE,6.35mm ID x 1200mm L | KOB |
| B4. | HM83C10030G1 | [2] | BOLT | KOBSems |
| B6. | YN64H01288P1 | [1] | CLAMP | KOB |
| B7. | ZM73C10020 | [2] | BOLT,M10x20mm - Course Thread | KOBSems |
| . . | YN64H00183F1 | [1] | Control, Block | |
| C1. | YN64H01336P1 | [1] | BLOCK | KOB |
| C2. | ZM73C08020 | [3] | BOLT,M8x20mm - Course Thread | KOBSems |
