神钢零件查询(200-8) - EXCAVATOR S/N YN11-45001 - (1/06-12/09) (188-01-1) - WINDOW ASSY, ROOF Kobelco
广数供应链运营团队, 15 02月, 2025，浏览：
680 次
| Pos. | Part No | Qty | Parts name | Comments |
|---|
| . . | YN02C03183F1 | [1] | WINDOW | KOBAssy, Roof |
| 1. | YN02C03627P1 | [1] | ROOF | KOB |
| 2. | YN02C03810F1 | [2] | LOCK | KOBAssy |
| 3. | YT02C01086P1 | [2] | GAS STRUT | KOB |
| 4. | YN02C03664P1 | [1] | PLATE | KOB |
| 5. | YN02C03640P1 | [1] | PLATE | KOB |
| 6. | YN02C03471P1 | [2] | SPACER | KOB |
| 7. | YN02C03187P2 | [2] | PLATE | SM |
| 8. | YN02C03194P1 | [2] | HINGE | KOB |
| 9. | ZM73C08025 | [4] | BOLT,M8x25mm - Course Thread | KOBSems |
| 10. | ZM66C06025 | [8] | BOLT | KOBSems |
| 11. | ZM66C06020 | [4] | BOLT | KOBSems |
| 12. | ZS18C08020 | [4] | SCREW,Hex, M8 x 20mm | KOBCap |
| 13. | YR21C01161P1 | [4] | WASHER,9mm ID x 22mm OD x 2.3mm Thk | KOB |
| 14. | ZM73C06016 | [4] | BOLT,M6x16mm - Course Thread | KOBSems |
| 15. | YN02C02967P1 | [1] | HANDLE | KOB |
| 17. | YT02C01390P1 | [4] | WASHER,9mm ID x 20mm OD x 0.8mm Thk | KOB |
| 18. | ZR36X00600 | [4] | SNAP RING | KOBE |
| 21. | YN02C02712P1 | [2] | PIN | KOB |
| 22. | YN02C03663P1 | [1] | PLATE | KOB |
| 23. | YN55C00008F1 | [1] | SUN VISOR | KOBAssy |
| 23-1. | YN55C00010P1 | [1] | SUN VISOR | KOB Superseded by part number: YN55C00017P1 |
| 23-2. | YN02C01953P2 | [1] | RAIL ASSY. | KOB |
| 23-3. | YN02C01954P1 | [1] | RAIL ASSY. | KOB |
| 23-4. | YN02C01955P1 | [1] | RAIL ASSY. | KOB |
| 23-5. | YN02C01875D1 | [8] | SCREW | KOBMachine |
| 23-6. | YN02C03200P1 | [1] | FOAM INSULATION | KOB |
| 23-7. | YN55C01018P1 | [1] | HANDLE | KOB |
| 24. | YN02C03379P1 | [14] | NUT | KOB |
| 25. | ZW16P06000 | [14] | WASHER | KOB |
| 26. | ZM46C06025 | [2] | BOLT | KOBSems |
| 27. | YN02C03641P1 | [2] | PLATE | SM |
