| Pos. |
Part No |
Qty |
Parts name |
Comments |
| 1. |
91N6-80010
|
[1] |
DECAL KIT(A)
|
|
| 1. |
91N6-80011
|
[1] |
DECAL KIT(A)
|
|
| 1-1. |
91E1-27110
|
[1] |
DECAL-LOW EMI ENGINE
|
|
| 1-2. |
91N6-01102
|
[1] |
DECAL-A/CLEANER FILTER
|
|
| 1-3. |
91N6-02120
|
[1] |
DECAL-BATT ACCIDENT
|
|
| 1-5. |
91N6-03140
|
[1] |
DECAL-FALLING
|
|
| 1-6. |
91N6-03111
|
[1] |
DECAL-OIL LUBRICATION
|
|
| 1-7. |
91N6-01111
|
[1] |
DECAL-T/CHARGER COVER
|
|
| 1-8. |
91N6-07121
|
[1] |
DECAL-SHEARING
|
|
| 1-9. |
91N6-07131
|
[1] |
NO STEP
|
|
| 1-10. |
91N6-01121
|
[1] |
DECAL-RADIATOR CAP
|
|
| 1-11. |
91N6-03130
|
[2] |
DECAL-H/PRESSURE HOSE
|
|
| 1-12. |
91N6-07252
|
[1] |
DECAL-SAFETY FR WINDOW
|
|
| 1-13. |
91N6-07280
|
[1] |
DECAL-HAMMER
|
|
| 1-14. |
91N6-07370
|
[1] |
DECAL-CABIN RH PILLAR
|
|
| 1-15. |
91N6-07261
|
[1] |
DECAL-ALTERNATE EXIT
|
|
| 1-16. |
91N6-07301
|
[1] |
CONSOLE BOX TILTING
|
|
| 1-16. |
92N6-07510
|
[1] |
CONSOLE BOX TILTING
|
|
| 1-17. |
91N6-07311
|
[1] |
DECAL-SAFETY LEVER
|
|
| 1-17. |
92N6-07310
|
[1] |
SAFETY LEVER
|
|
| 1-18. |
91N6-07272
|
[1] |
DECAL-AIRCON FILTER
|
|
| 1-19. |
91N6-05110
|
[4] |
SLINGING IDEOGRAM
|
|
| 1-20. |
91N6-05120
|
[2] |
TIE
|
|
| 2. |
91N6-80020
|
[1] |
DECAL KIT(B)
|
|
| 2. |
91N6-80021
|
[1] |
DECAL KIT(B)
|
|
| 2. |
91N6-80022
|
[1] |
DECAL KIT(B)
|
|
| 2. |
91N6-80030
|
[1] |
DECAL KIT(B)
|
|
| 2. |
91N6-80031
|
[1] |
DECAL KIT(B)
|
|
| 2. |
91N6-80032
|
[1] |
DECAL KIT(B)
|
|
| 2-1. |
91N6-17112
|
[1] |
MODEL NAME-LH/RR
|
|
| 2-1. |
91N6-17113
|
[1] |
MODEL NAME
|
|
| 2-1. |
91N6-17310
|
[1] |
MODEL NAME-LH/RR
|
|
| 2-1. |
91N6-17311
|
[1] |
MODEL NAME
|
|
| 2-2. |
91N6-17210
|
[1] |
DECAL-M/NAME, LH/FR
|
|
| 2-3. |
91N6-17122
|
[1] |
MODEL NAME-RH/RR
|
|
| 2-3. |
91N6-17320
|
[1] |
MODEL NAME-RH/RR
|
|
| 2-4. |
91N5-17220
|
[1] |
DECAL-M/NAME, RH/FR
|
|
| 2-5. |
91N6-17140
|
[2] |
ROBEX LOGO
|
|
| 2-6. |
91N6-21110
|
[2] |
TRADE MARK
|
|
| 2-7. |
91N6-21110
|
[1] |
TRADE MARK
|
|
| 2-8. |
91N6-17265
|
[1] |
SERVICE INSTRUCTION
|
|
| 2-8. |
91N6-17266
|
[1] |
SERVICE INSTRUCTION
|
|
| 2-9. |
91N6-06110
|
[2] |
DECAL-KEEP CLEAR-ATTACH
|
|
| 2-10. |
91N6-04101
|
[2] |
KEEP CLEAR-REF
|
|
| 2-10. |
91N6-04170
|
[2] |
REFLECTING
|
|
| 2-11. |
91N6-04122
|
[2] |
KEEP CLEAR/RR
|
|
| 2-12. |
91N6-07102
|
[2] |
DECAL-KEEP CLEAR
|
|
| 2-13. |
91N6-04132
|
[2] |
LIFTING EYE
|
|
| 2-14. |
91N6-03102
|
[1] |
HYD OIL LEVEL
|
|
| 2-15. |
91N6-07112
|
[3] |
DECAL-STAY FIX
|
|
| 2-16. |
91N6-07141
|
[1] |
TRANSPORTING
|
|
| 2-17. |
91N6-03121
|
[1] |
REDUCTION GEAR GREASE
|
|
| 2-18. |
91N6-01131
|
[1] |
FUELING
|
|
| 2-19. |
91LB-01350
|
[1] |
DECAL-ECM CONNECTOR
|
|
| 2-20. |
91N6-07390
|
[1] |
DECAL-TURBOCHARGER
|
|
| 4. |
@
|
[1] |
LIFTING CHART KIT
|
|
| 4-2. |
91N6-17411
|
[1] |
LIFTING CHART(3.8CWT)
|
|
| 4-3. |
91N6-19410
|
[1] |
LIFTING CHART(R210-7)
|
|
| 4-8. |
91N6-17440
|
[1] |
LIFTING CHART-L/REACH
|
|
| 4-13. |
91N6-17610
|
[1] |
LIFTING CHART(4.2CWT)
|
|
| 4-17. |
91N6-17710
|
[1] |
LIFTING CHART(4.5CWT)
|
|
| 5. |
91N6-07201
|
[1] |
CONTROL IDEOGRAM
|
|
| 5. |
91N6-08200
|
[1] |
CONTROL IDEOGRAM
|
|
| 6. |
91N6-07212
|
[1] |
DECAL-CNTL IDEOGRAM,LH
|
|
| 6. |
92N6-07210
|
[1] |
CONTROL IDEOGRAM-LH
|
|
| 6. |
91N6-08210
|
[1] |
DECAL-CNTL IDEOGRAM,LH
|
|
| 6. |
92N6-08210
|
[1] |
CONTROL IDEOGRAM
|
|
| 7. |
91N6-07221
|
[1] |
DECAL-CNTL IDEOGRAM,RH
|
|
| 7. |
92N6-07220
|
[1] |
CONTROL IDEOGRAM-RH
|
|
| 8. |
91N6-27510
|
[2] |
DECAL-SAFETY
|
|
| 9. |
91E1-26300
|
[7] |
DECAL-STEP TREAD
|
|
| 10. |
91N6-14160
|
[1] |
NAME PLATE
|
|
| 10. |
91N6-14170
|
[1] |
NAME PLATE
|
|
| 11. |
91EK-12010
|
[4] |
RIVET
|
|
| 12. |
91N6-14180
|
[1] |
NAME PLATE-BUCKET
|
|
| 13. |
91N6-06420
|
[4] |
METAL TACK
|
|
| 14. |
91N6-07330
|
[1] |
DECAL-LOCKING CLAMP
|
|
| 15. |
91N6-03200
|
[1] |
DECAL-ACCUMULATOR
|
|
