凯斯零件查询(4330) - TITAN FLOATER (6/98-8/99) (02-001[03]) - ENGINE GROUP (4330 ONLY) Case Agriculture
广数供应链运营团队, 15 02月, 2025，浏览：
554 次
| Pos. |
Part No |
Qty |
Parts name |
Comments |
| 1. |
BN247218
|
[2] |
Hardened 3/4WA17
|
|
| 2. |
BN281510
|
[1] |
0102-12-8
|
|
| 3. |
BN1420062
|
[1] |
1/2 X 2 STD
|
|
| 4. |
BN1470404C
|
[3] |
LOCK NUT
|
BN
NC 3/8-16 Flex Lock Superseded by part number: 231-4146
|
| 5. |
BN1470406C
|
[4] |
LOCK NUT
|
BN
NC 1/2-13 Flex Lock Superseded by part number: 231-4148
|
| 6. |
BN1470409C
|
[2] |
LOCK NUT
|
BN
NC 3/4-10 Flex Lock Superseded by part number: 280375
|
| 7. |
BN1913320C
|
[2] |
HH 7/16-14 X 1 NC G
|
|
| 8. |
413-1216
|
[2] |
BOLT,Hex, 3/4" - 10 x 1", Gr 5
|
CAS
|
| 9. |
BN1913329C
|
[8] |
HH 1/2-13 X 1-1/4 N
|
|
| 10. |
BN1913335C
|
[4] |
BOLT
|
BN
HH 3/8-16 X 1-1/2 Superseded by part number: 413-624
|
| 11. |
BN1913378C
|
[2] |
BOLT
|
BN
1/2-13 X 2.5, HH, G8 Superseded by part number: 426-840
|
| 12. |
280210
|
[2] |
BOLT,Hex, 3/4"-10 x 4", G5
|
WIN
|
| 13. |
BN1913453C
|
[6] |
HH 3/8-16 X 4-1/2 N
|
|
| 14. |
BN1913657C
|
[2] |
HH 1/2-13 X 3-1/4
|
|
| 15. |
BN1913695F
|
[10] |
BOLT
|
BN
HH 7/16 X 1-3/4 NF
|
| 17. |
BN2290273
|
[1] |
BUSHING
|
BN
0102-8-6
|
| 18. |
BN2290278
|
[1] |
BUSHING
|
BN
0102-6-2
|
| 19. |
BN2290291
|
[1] |
BUSHING
|
BN
0102-4-2
|
| 20. |
BN2290298
|
[1] |
BUSHING
|
BN
0102-12-6
|
| 21. |
BN2292195
|
[1] |
CAT 3208T330HP
|
|
| 21A. |
BN2292195-001
|
[1] |
Advance Timing-CAT
|
|
| 22. |
BN2292249
|
[2] |
HYDRAULIC VALVE
|
BN
Heater Everhot
|
| 23. |
BN2292371
|
[4] |
NUT
|
BN
3/8, FW, G8
|
| 24. |
BN51674
|
[1] |
HOSE CLAMP
|
BN
Adjustable #40
|
| 25. |
BN2293521
|
[1] |
FITTING
|
BN
2102-6-6
|
| 26. |
BN2293687
|
[1] |
FITTING
|
BN
744240
|
| 28. |
BN2297361
|
[2] |
KIT
|
BN
Lord
|
| 29. |
BN2297362
|
[2] |
ENGINE MOUNT
|
BN
Lord
|
| 31. |
BN2303412
|
[6] |
LOCK WASHER
|
BN
3/8 Superseded by part number: 80680
|
| 32. |
BN2303414
|
[2] |
7/16
|
|
| 33. |
BN2303421
|
[2] |
3/4
|
|
| 34. |
2392096
|
[1] |
SENSOR
|
CUR
Oil Datcon Superseded by part number: 311366
|
| 35. |
BN2392312
|
[2] |
WASHER
|
BN
Mount
|
| 37. |
BN2393603
|
[1] |
FITTING
|
BN
2103-8-10
|
| 38. |
BN2393814
|
[1] |
HOSE
|
BN
Gates 26513 2" X 33
|
| 39. |
BN2394668
|
[1] |
PULLEY
|
BN
Engine 8"
|
| 40. |
BN2394965
|
[1] |
TEMPERATURE SENDER
|
BN
|
| 41. |
BN2396570
|
[1] |
FAN
|
BN
8-Blade 26"/3208
|
| 42. |
BN2401945
|
[1] |
SENDER UNIT
|
BN
Tachometer
|
| 43. |
BN2404997
|
[1] |
PRESSURE SWITCH
|
BN
N.O.
|
| 44. |
BN303492
|
[1] |
SPACER
|
BN
330, CAT
|
| 45. |
BN303781
|
[1] |
FAN
|
BN
Tightener Bracket
|
| 46. |
NSS
|
[1] |
NOT SOLD SEPARAT
|
CON
Assembly, Throttle
|
| 48. |
BN7136209
|
[1] |
BRACKET
|
BN
Freon Compressor
|
| 50. |
BN7146201
|
[1] |
CROSSMEMBER
|
BN
Engine-Front
|
| 51. |
BN7146202
|
[2] |
MOUNTING PLATE
|
BN
Engine-Rear
|
| 53. |
BN2303415
|
[1] |
1/2, LW, G5
|
|
| 54. |
BN1913338C
|
[12] |
HH 3/8-16 X 1-1/2 G8
|
|
