神钢零件查询(200-8) - EXCAVATOR S/N YN11-45001 - (1/06-12/09) (265-01-1) - GAUGE ASSY, CLUSTER Kobelco
广数供应链运营团队, 15 02月, 2025，浏览：
988 次
| Pos. | Part No | Qty | Parts name | Comments |
|---|
| . . | YN59S00021F1 | [1] | CONTROL MONITOR | SMGauge Assy, Cluster, Serial Range: YQ11-06001-YQ11-06098 Superseded by part number: YN59S00021F3 |
| . . | YN59S00021F2 | [1] | GAUGE | KOBGauge Assy, Cluster, Serial Range: YQ11-06099-YQ11-06353 Superseded by part number: YN59S00021F3 |
| 1. | YN59S00021S001 | [1] | CONTROL MONITOR | SMGauge |
| . . | YN59S00021F3 | [1] | CONTROL MONITOR | SMGauge Assy, Cluster, Start Serial: YQ11-06354 |
| 2. | YN59S00021S002 | [1] | PRINTED CIRCUIT BOAR | SMPrinted Board |
| 3. | YN59S00021S003 | [1] | COVER | SMCase |
| 4. | YN59S00021S004 | [1] | COVER | SMCase |
| 5. | YN59S00021S005 | [1] | BUZZER | SM |
| 6. | YN59S00021S006 | [1] | PANEL | SM |
| 7. | YN59S00021S007 | [6] | SCREW | SM |
| 8. | YN59S00021S008 | [6] | SCREW | SM |
| 9. | YN59S00021S009 | [2] | SCREW | SM |
| 10. | YN59S00021S010 | [7] | SCREW | SM |
