神钢零件查询(200-8) - EXCAVATOR S/N YN11-45001 - (1/06-12/09) (272-01-1) - RELAY BOX ASSY Kobelco
广数供应链运营团队, 15 02月, 2025，浏览：
242 次
| Pos. | Part No | Qty | Parts name | Comments |
|---|
| . . | YN24E00016F1 | [1] | RELAY | KOBBox Assy YQ11-06001 to YQ11 -06079 Superseded by part number: YN24E00016F3 |
| . . | YN24E00016F2 | [1] | RELAY | KOBBox Assy, Start Serial: YQ11-06080 Superseded by part number: YN24E00016F3 |
| 1. | YN24E00016S001 | [1] | BOX | SMHousing |
| 2. | YN24E00016S002 | [1] | BOX | SMHousing |
| 3. | YN24E00016S003 | [1] | FUSE BOX | SMCover |
| 4. | YN24E00016S004 | [1] | PRINTED CIRCUIT BOAR | SM Superseded by part number: YN24E00016F3 |
| 5. | YN24E00016S005 | [11] | FUSE,5amp | SM5 Amp |
| 6. | YN24E00016S006 | [9] | FUSE,10amp | SM10 Amp |
| 7. | YN24E00016S007 | [6] | FUSE,15amp | SM15 Amp |
| 8. | YN24E00016S008 | [10] | FUSE,20amp | SM20 Amp |
| 9. | YN24S00010P1 | [8] | RELAY | KOB |
| 10. | YN24S00012P1 | [4] | RELAY | KOB(For F1 Only) Superseded by part number: YN24S00012P2 |
| 11. | YN24E00016S011 | [1] | HANDLE | SM |
| 12. | YN24E00016S012 | [1] | WIRE CONNECTOR | SM |
| 13. | YN24E00016S013 | [3] | MULTIPOLE CONNECTOR | SM |
| 14. | YN24S00012P2 | [4] | RELAY,24V | SM(For F2 Only) |
