凯斯零件查询(4330) - TITAN FLOATER (6/98-8/99) (02-007) - FUEL TANK GROUP Case Agriculture
广数供应链运营团队, 15 02月, 2025，浏览：
688 次
| Pos. |
Part No |
Qty |
Parts name |
Comments |
| 1. |
BN2395008-002
|
[2] |
STRAP
|
TYR
Assembly, Fuel Tank
|
| 2. |
87267439
|
[2] |
BRACKET, SUPPORTING
|
TYR
Fuel Tank
|
| 3. |
BN2395008
|
[1] |
TANK
|
TYR
Fuel, 120 Gallon
|
| 4. |
87484460
|
[10] |
BELT,76.67 mm W x 6096.00 mm L
|
BRR
4 Ply, Cut To Fit
|
| 5. |
BN2390873
|
[1] |
HOSE,0.31" ID
|
BN
Fuel, 815-25R
|
| 6. |
BN7133010
|
[1] |
TUBE
|
BN
Fuel P/U Tube
|
| 7. |
BN306489
|
[1] |
ASSEMBLY
|
BN
Fuel Tube TYP, 20"
|
| 8. |
BN2290561
|
[1] |
FITTING
|
BN
2103-8-6
|
| 9. |
50285
|
[8] |
|
BOLT Hex, 1/2"-13 x 1 1/2", G5, Full Thd
|
| 10. |
BN300407
|
[8] |
FLANGE NUT
|
BN
Flg, 1/2"-13, G8
|
| 11. |
86624188
|
[8] |
WASHER,0.53" ID x 1.06" OD x 0.13" Thk
|
GI
|
| 12. |
BN2395003-005
|
[2] |
NUT
|
BN
Fuel Tank Strap Superseded by part number: 87343935, 87310599
|
