现代零件查询R210LC-7(#98001-) BUCKET(1.05M3 SAE HEAPED, ROCK)EPC Hyundai
广数供应链运营团队, 15 02月, 2025，浏览：
351 次
| Pos. |
Part No |
Qty |
Parts name |
Comments |
| . |
63N6-36000
|
[1] |
BUCKET ASSY
|
|
| . |
63N6-36000BG
|
[1] |
BUCKET ASSY
|
|
| 1. |
63N6-36010
|
[1] |
BUCKET WA
|
|
| 1. |
63N6-36010BG
|
[1] |
BUCKET WA
|
|
| 1-1. |
61N8-31320
|
[5] |
ADAPTER-TOOTH
|
|
| 2. |
61N8-31310
|
[5] |
POINT-TOOTH
|
|
| 2. |
61N8-31310BG
|
[5] |
POINT-TOOTH
|
|
| K3. |
E262-5004
|
[5] |
NUT-HEX
|
|
| 4. |
61N6-30600
|
[1] |
BUSHING
|
|
| 5. |
61N6-31360
|
[1] |
PLATE-COVER
|
|
| 6. |
61N6-31410
|
[5] |
SHIM(1.0T)
|
|
| 7. |
S017-160452
|
[3] |
BOLT-HEX
|
|
| 8. |
S441-160002
|
[3] |
WASHER-HARDENED
|
|
| K9. |
61E5-11150
|
[5] |
WASHER-LOCK
|
|
| K. |
E262-5004-S
|
[1] |
TOOTH PIN KIT
|
|
