凯斯零件查询(4330) - TITAN FLOATER (6/98-8/99) (03-001[01]) - TRANSMISSION GROUP Case Agriculture
广数供应链运营团队, 15 02月, 2025，浏览：
826 次
| Pos. |
Part No |
Qty |
Parts name |
Comments |
| 1. |
BN1470408C
|
[4] |
LOCK NUT
|
BN
NC 5/8-11 Flex Lock Superseded by part number: 85700693
|
| 2. |
9627896
|
[4] |
BOLT,Hex, 5/8" - 11 x 1 3/4", Gr 5
|
NH
|
| 3. |
BN2293131
|
[1] |
FITTING
|
BN
0503-12-16
|
| 4. |
BN2296633
|
[1] |
FITTING
|
BN
2061-12-16
|
| 5. |
80679
|
[2] |
LOCK WASHER,1/20.507 CST ZND
|
NH
|
| 6. |
BN302159
|
[1] |
WIRE HARNESS
|
BN
Transmission, Interface
|
| 7. |
BN304256
|
[1] |
TRANSMISSION
|
BN
Allsion MD3060
|
| 7A. |
2402071-002
|
[1] |
FILTER
|
CUR
Oil Superseded by part number: 306288
|
| 7B. |
BN2402071-003
|
[3] |
BALANCER
|
BN
29503328
|
| 7C. |
BN2402071-004
|
[1] |
PLATE
|
BN
29503696
|
| 7D. |
BN2402071-005
|
[1] |
DIPSTICK
|
BN
Transmission Fluid
|
| 7E. |
BN2402071-006
|
[1] |
PLATE
|
BN
|
| 7F. |
BN2402071-007
|
[1] |
Ring 29503695
|
|
| 7G. |
BN2402071-008
|
[1] |
RING GEAR
|
BN
Assembly
|
| 7H. |
BN2402071-009
|
[1] |
SENSOR
|
BN
Throttle Position
|
| 7J. |
BN2402071-010
|
[1] |
MOUNTING PLATE
|
BN
TPS Bracket
|
| 7K. |
BN2402071-011
|
[1] |
WIRE HARNESS
|
BN
VIM 29506606
|
| 7L. |
BN2402071-012
|
[1] |
WIRE HARNESS
|
BN
VIM 29518142
|
| 7M. |
BN2402071-013
|
[1] |
WIRE HARNESS
|
BN
29518270
|
| 7N. |
BN2402071-014
|
[1] |
MODULE
|
BN
Vehicle Interface
|
| 7P. |
BN2402071-015
|
[1] |
Electronic Control Unit
|
|
| 7Q. |
BN2402071-016
|
[1] |
REPAIR KIT
|
BN
Adaptation 295/330
|
| 8. |
BN7146462
|
[1] |
MOUNT
|
BN
MD Harness Support
|
