神钢零件查询(200-8) - EXCAVATOR S/N YN11-45001 - (1/06-12/09) (310-01A-1) - HARNESS ASSY, UPP Kobelco
广数供应链运营团队, 15 02月, 2025，浏览：
316 次
| Pos. | Part No | Qty | Parts name | Comments |
|---|
| . . | YN13E00095F1 | [1] | HARNESS | KOBAssy, Upper |
| A1. | YN13E01446P9 | [1] | HARNESS | KOB |
| A2. | YN13E01417P1 | [1] | CABLE | KOB |
| A3. | YN13E01441P2 | [1] | CABLE,300mm L | KOB |
| A4. | LC13E01144P1 | [1] | CABLE | KOB |
| A5. | YN13E01442P1 | [1] | CABLE | KOB |
| A5-1. | LQ13E01099S002 | [1] | FUSE,70 Amp | KOBFusible Link |
| A6. | YN13E01482P1 | [1] | HARNESS | KOB |
| A11. | YN13E01375P1 | [27] | CLIP,M8 x 8.20mm Shank | KOB |
| A12. | PY01P01043D3 | [77] | CABLE TIE,188mm L | KOB |
| A13. | EW02E01015D4 | [4] | CLIP | KOB |
| A14. | EW02E01015D6 | [3] | CLIP | KOB |
| A16. | EW02E01015D9 | [2] | CLIP,20mm ID, P Type | KOB |
| A17. | EW02E01015DA | [1] | CLIP | KOB |
| A19. | CM92H01030P1 | [2] | CLIP | KOB |
| A22. | LC13E01248P1 | [1] | BRACKET | KOB |
| A23. | LQ13E01155P1 | [1] | BRACKET | KOB |
| A25. | ZM73C08020 | [18] | BOLT,M8x20mm - Course Thread | KOBSems |
| A29. | ZW26X08000 | [1] | LOCK WASHER | KOBLock Superseded by part number: 83990583 |
| A30. | PY01P01043D8 | [4] | CABLE TIE,102mm L | KOB |
| A32. | ZN18C08007 | [4] | NUT | KOBM08x1.25mm |
| A33. | LC13E01150P1 | [1] | PLATE | KOBBracket |
| A35. | PX32W01059P1 | [1] | COLLAR | KOB |
| A36. | LE13E01006P1 | [1] | HARNESS | KOBCable |
| A37. | LC13E01180P2 | [1] | CABLE,180mm L | KOB |
| A38. | LQ13E01100P1 | [1] | CABLE | KOB |
| A39. | EW02E01015DC | [1] | CLIP | KOB |
| A40. | LQ13E01109P1 | [1] | BRACKET | KOB |
| A41. | LQ13E01093P1 | [1] | GROMMET | KOB |
| A42. | LC13E01192P1 | [1] | GROMMET | KOB Superseded by part number: LC13E01330P1 |
| A43. | YA21C01019D1 | [1] | SPACER | KOBTrim |
| A44. | EB54H01044P1 | [3] | CLIP | KOB |
| A45. | EW02E01015D3 | [1] | CLIP | KOB |
| A47. | ZM73C08016 | [3] | BOLT,M8x16mm - Course Thread | KOBSems |
| A48. | ZM73C08025 | [1] | BOLT,M8x25mm - Course Thread | KOBSems |
| A49. | ZM73C10020 | [7] | BOLT,M10x20mm - Course Thread | KOBSems |
| A50. | ZM73C12020 | [1] | BOLT,M12x20mm - Course Thread | KOBSems |
| A51. | ZW16P08000 | [4] | WASHER | KOB |
| A52. | LC13E01193P1 | [1] | HARNESS | KOB |
| B1. | LC03Z00036P1 | [1] | Elec [ NOT IN service] | |
