凯斯零件查询(4330) - TITAN FLOATER (6/98-8/99) (06-001) - HYDRAULIC ASSEMBLY Case Agriculture
广数供应链运营团队, 15 02月, 2025，浏览：
560 次
| Pos. |
Part No |
Qty |
Parts name |
Comments |
| 1. |
NSS
|
[1] |
NOT SOLD SEPARAT
|
CON
Hydraulic Tank Group
|
| 6. |
BN3600010-028.52
|
[1] |
Assy 881-20-01
|
|
| 7. |
BN3600004-052.96
|
[1] |
Assy 451AR-10-01
|
|
| 8. |
BN3600003-050.70
|
[1] |
Assy 451AR-8-01
|
|
| 9. |
BN3600010-034.52
|
[1] |
Assy 881-20-01
|
|
| 10. |
BN3600005-022.06
|
[1] |
Assy 451AR-12-01
|
|
| 11. |
BN3600003-094.70
|
[1] |
Assy 451AR-08-01
|
|
| 12. |
BN3600003-106.70
|
[1] |
Assy 451 AR-8-01
|
|
| 13. |
BN3600003-036.70
|
[2] |
Assy 451 AR-8-01
|
|
