凯斯零件查询(4330) - TITAN FLOATER (6/98-8/99) (01-001) - DASH CONTROLS Case Agriculture
广数供应链运营团队, 15 02月, 2025，浏览：
819 次
| Pos. |
Part No |
Qty |
Parts name |
Comments |
| 1. |
BN2296753
|
[1] |
GAUGE
|
BN
Voltmeter
|
| 2. |
BN304524
|
[1] |
SPEEDOMETER
|
BN
Speedo, 3.38 X 80 MPH W/OD
|
| 3. |
BN2291214
|
[1] |
INDICATOR LIGHT
|
BN
Blue
|
| 4. |
86636599
|
[1] |
TACHOMETER
|
PA
3.38 x 3K With Hourmeter
|
| 5. |
BN2296752
|
[1] |
FUEL GAUGE
|
BN
|
| 6. |
BN304540
|
[1] |
DASH PANEL
|
BN
Left
|
| 6A. |
88769
|
[4] |
HEX SOC SCREW,BTN HD, 1/4" - 20 x 1/2"
|
WIN
|
| 7. |
BN2296754
|
[1] |
OIL PRESSURE GAUGE
|
BN
"Smart"
|
| 8. |
BN2296730
|
[1] |
GAUGE
|
BN
Water Temp "Smart”
|
| 9. |
BN2293217
|
[1] |
BUZZER
|
BN
Do Not Shift Light
|
| 10. |
BN65223
|
[1] |
POWER SOCKET
|
BN
Outlet, 12V
|
| 10A. |
BN2404968
|
[4] |
SELF-TAP SCREW,#8 x 5/8"
|
BN
HH #8 X 5/8 SLFTAP
|
| 11. |
BN2291956
|
[3] |
SWITCH
|
BN
Cutler Hammer
|
| 12. |
BN2291234
|
[4] |
INDICATOR LIGHT
|
BN
Indicator Red
|
| 13. |
BN2401950
|
[1] |
IGNITION SWITCH
|
BN
|
| 14. |
BN304547
|
[1] |
GAUGE
|
BN
Hydraulic Oil Temperature 100-240 W/TR200
|
| 15. |
BN2294958
|
[1] |
SWITCH
|
BN
Windshield Wiper Superseded by part number: V91873
|
| 16. |
BN2390774
|
[1] |
GAUGE
|
BN
Air Pressure
|
| 19. |
BN2291152
|
[1] |
REPAIR KIT
|
BN
Low Air Pressure 326
|
| 21. |
BN29445
|
[1] |
SWITCH
|
BN
On-Off-On
|
| 22. |
BN305723
|
[1] |
Pneumatic Throttle
|
|
| 22A. |
BN29618
|
[1] |
MOUNTING PLATE
|
BN
10 ga HRS 3.5 x 10.5
|
| 22B. |
BN50823
|
[4] |
BOLT
|
BN
5/16-18 X 1, HH, G5 Superseded by part number: 9635884
|
| 22C. |
BN55360
|
[4] |
LOCK NUT
|
BN
5/16"-18, NLN, G5 Superseded by part number: 280736
|
| 24. |
BN304541
|
[1] |
Left Dash Assembled
|
|
| 25. |
BN7142150
|
[1] |
SHEET
|
BN
Blank Panel (For Foam Marker Option)
|
| 26. |
BN8196083
|
[1] |
SHEET
|
BN
Right Side Panel, Blank (Chassis Only)
|
| 27. |
BN2290807
|
[2] |
INDICATOR LIGHT
|
BN
Green
|
| 27A. |
BN2290270
|
[2] |
BULB
|
BN
330
|
| 27B. |
BN2291235
|
[2] |
LAMP SOCKET
|
BN
Light Indicator
|
