凯斯零件查询(4330) - TITAN FLOATER (6/98-8/99) (01-003) - STEERING ASSEMBLY Case Agriculture
广数供应链运营团队, 15 02月, 2025，浏览：
122 次
| Pos. |
Part No |
Qty |
Parts name |
Comments |
| 1. |
BN2396330
|
[1] |
STEERING COLUMN
|
BN
Assembly
|
| . . |
BN2396330-001
|
[1] |
REPAIR KIT
|
BN
Turn Signal Repair Kit
|
| 2. |
BN2298398
|
[1] |
STEERING WHEEL
|
BN
|
| 3. |
BN2292560
|
[1] |
YOKE
|
BN
W/ U-Joint
|
| 3A. |
BN2294188
|
[1] |
REPAIR KIT
|
BN
U-Joint Kit
|
| 4. |
BN1470404C
|
[4] |
LOCK NUT
|
BN
NC 3/8-16 Flex Lock Superseded by part number: 231-4146
|
| 5. |
BN27314
|
[1] |
CAP
|
BN
Steer Wheel W/"Tyler"
|
| 6. |
BN7142237
|
[1] |
SUPPORT
|
BN
Support Column
|
| 7. |
BN50995
|
[1] |
LOCK NUT
|
BN
3/8"-24 UNF, Centerloc
|
| 8. |
BN7142247
|
[1] |
MOUNTING PLATE
|
BN
Steering Valve
|
| 9. |
BN7142172
|
[2] |
Steering Column
|
|
| 10. |
BN7142246
|
[1] |
MOUNTING PARTS
|
BN
Steering Valve
|
| 11. |
BN50254
|
[8] |
BOLT,3/8"-16 x 1", Stainless
|
BN
|
| 12. |
BN2294495
|
[4] |
LOCK NUT
|
BN
3/8-16 SS Flex Lock
|
| 13. |
BN1913319C
|
[4] |
BOLT
|
BN
HH 3/8-16 X 1 NC Superseded by part number: 413-616
|
| 14. |
BN1913309F
|
[4] |
BOLT
|
BN
HH 3/8-24 X 3/4 NF
|
| 15. |
87529233
|
[10] |
WASHER,0.41" ID x 0.81" OD x 0.09" Thk
|
BN
3/8"
|
| 16. |
BN2392391
|
[8] |
WASHER
|
BN
Flat 3/8 SS
|
| 17. |
BN1913354F
|
[1] |
BOLT
|
BN
HH 5/16-24 X 2 NF
|
| 18. |
BN1470403F
|
[1] |
LOCK NUT
|
BN
NF 5/16-24 Flex Lock
|
| 19. |
BN2395066
|
[2] |
SEAL
|
BN
Trim, SD-161
|
| 20. |
BN2303411
|
[4] |
LOCK WASHER
|
BN
5/16
|
| 21. |
BN1913308C
|
[4] |
HH 5/16-18 X 3/4 NC
|
|
| 22. |
BN1913345F
|
[1] |
BOLT
|
BN
HH 3/8-24 X 1 3/4
|
| 23. |
BN1470405F
|
[2] |
LOCK NUT
|
BN
NF 7/16-20 Flex Lock
|
| 24. |
BN1913336F
|
[2] |
HH 7/16-20 X 1-1/2
|
|
| 25. |
NSS
|
[1] |
NOT SOLD SEPARAT
|
CON
Orbitrol, Steering
|
