神钢零件查询(200-8) - EXCAVATOR S/N YN11-45001 - (1/06-12/09) (340-01-1) - RING ASSY, SLEWING (IN-HOUSE PRODUCT) Kobelco
广数供应链运营团队, 15 02月, 2025，浏览：
274 次
| Pos. | Part No | Qty | Parts name | Comments |
|---|
| . . | YN40F00027F1 | [1] | Slewing (in-house Product) | |
| 1. | YN40F00026F1 | [1] | RING | KOBSlewing Superseded by part number: YN40F00026F2 |
| 1-1. | NSS | [1] | NOT SOLD SEPARAT | CONOuter |
| 1-1A. | NSS | [1] | NOT SOLD SEPARAT | CONOuter |
| 1-1B. | YN40F01020P1 | [1] | PLUG | KOB |
| 1-1C. | 2419T1964D1 | [1] | PIN | KOBTaper |
| 1-2. | NSS | [1] | NOT SOLD SEPARAT | CONInner |
| 1-3. | 2425T307 | [120] | BALL | KOB |
| 1-4. | YN40F01018P1 | [120] | RETAINER | KOB |
| 1-5. | YN40F01019D1 | [1] | SEAL | KOB, Serial Range: YQ11-06001-YQ11-06679 Superseded by part number: YN40F01024D4 |
| . . | YN40F01024D1 | [1] | SEAL | KOB, Start Serial: YQ11-06680 Superseded by part number: YN40F01024DC |
| 1-6. | YN40F01019D2 | [1] | SEAL | KOB, Serial Range: YQ11-06001-YQ11-06679 Superseded by part number: YN40F01024D4 |
| . . | YN40F01024D2 | [1] | SEAL | KOB, Start Serial: YQ11-06680 Superseded by part number: YN40F01024DC |
| 1-7. | YN22T00194P1 | [1] | TYPE PLATE | KOBName Plate |
| 1-8. | 2420Z1036D3 | [2] | CLEVIS | KOB |
| 1-9. | ZG91S02000 | [1] | LUBE NIPPLE,1/8" NPT x 1/8" NPT | KOBNipple, 1/8" PT -- Straight |
| 2. | YN40F01001P1 | [36] | CAP | KOB |
| . . | YN40F00034F1 | [1] | Slewing | |
| A1. | YN40F00033F2 | [1] | SLEWING RING | SMSlewing |
| A1-3. | NSS | [120] | NOT SOLD SEPARAT | CONBall |
| A1-4. | NSS | [120] | NOT SOLD SEPARAT | CONSpacer |
| A1-6. | NSS | [1] | NOT SOLD SEPARAT | CONStopper |
| A1-7. | NSS | [1] | NOT SOLD SEPARAT | CONPin, Taper |
| A1-10. | NSS | [1] | NOT SOLD SEPARAT | CONFitting, Grease |
| A1-11. | NSS | [1] | NOT SOLD SEPARAT | CONName, Plate |
| A1-12. | NSS | [2] | NOT SOLD SEPARAT | CONRivet |
| A1-13. | NSS | [1] | NOT SOLD SEPARAT | CONRace, Outer |
| A1-14. | NSS | [1] | NOT SOLD SEPARAT | CONRace, Inner |
| A1-15. | YN40F01024D2 | [1] | SEAL | KOB Superseded by part number: YN40F01024DC |
| A1-16. | YN40F01024D1 | [1] | SEAL | KOB Superseded by part number: YN40F01024DC |
| A2. | YN40F01001P1 | [36] | CAP | KOB |
